WEINIG Univar 12 NC

Number of spindles: 4 St.
Number of tools: variabel St.
Spindle diameter: 50 mm
Spindle length: 320,320,320,160 mm
WEINIG UNIVAR 12 NC AUTOMATIC PROFILING AND MILLING MACHINE
-----------------------------------------
Machine can still be seen in operation!
Includes mechanization/handling equipment.

For milling the perimeter of windows, doors, and similar items
with non-uniform (varying) profiles.
For profiling individual components. PROCESSING UNITS
-----------------------------------------

1. Profiling Spindle
-----------------------------------------
Motor power: 11 kW (15 hp)
Spindle diameter: 50 mm
Spindle speed: 6000 rpm
Tool clamping length: 320 mm
Number of tool positions: variable, infinitely adjustable via NC
Radial and axial adjustment: NC-controlled axes
Synchronous feed device with automatic plunge function

2. Profiling Spindle
-----------------------------------------
Motor power: 11 kW (15 hp)
Spindle diameter: 50 mm
Spindle speed: 6000 rpm
Tool clamping length: 320 mm
Number of tool positions: variable, infinitely adjustable via NC
Radial and axial adjustment: NC-controlled axes

3. Profiling Spindle
-----------------------------------------
Motor power: 11 kW (15 hp)
Spindle diameter: 50 mm
Spindle speed: 6000 rpm
Tool clamping length: 320 mm
Number of tool positions: variable, infinitely adjustable via NC
Radial and axial adjustment: NC-controlled axes

Profile Milling Unit (vertical, right-hand side) at the end of the machine
-----------------------------------------
Spindle diameter: 40 mm
Tool clamping length: 160 mm
Axial adjustment with 8 positions
Radial indexing with 8 positions for profile milling

Includes:
--------------------------------------- --
Mechanization/Handling system

Control System:
-----------------------------------------
AALTRONIC

(Technical specifications as provided by the manufacturer – subject to change/no guarantee!)
