torna kullanılmış satılık (3,080)

turning length: 2000 mmturning diameter: 560 mmturning diameter over slide: 350 mmturning speeds: 25 - 1500 U/minswing diameter over bed slide: 350 mmturning dia. in gap: 785 mmquill travel: 180 mmquill:: 5 MKspindle bore: 105 mmengine output: 7,5 kWspindle taper: DIN 55029 D 1-8weight of the machine ca.: 2720 kg.Equipment:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-315 mm / D8- Clamping disc 450 mm- Fixed steady rest - passage diameter max. 180 mm- Follow-on steady rest - passage diameter max. 120 mm- 2 centering points- Initial filling with Shell Tellus 46- Motor with magnetic brake in accordance with CE standard- Foot pedal with brake function in accordance with CE- Coolant system- Quick-change tool holder with 4 inserts- Protective device for quick-change tool holder- Slip clutch- LED machine light- Change gears- Reduction sleeve- Chip back wall- Operating tool ...

turning length: 1000 mmturning diameter: 350 mmturning dia. in gap: 450 mmspindle bore: 40,0 mmturning speeds: 70 - 2000 U/minbed width: 180 mmspindle taper: 55029 D 1-4taper in tailstock: 3 MKquill travel: 110 mmtotal power requirement: 1,5 kWweight of the machine ca.: 529 kg.range L-W-H: 1730x700x1340 mmScope of delivery:- 3-axis digital display i200 with LCD display- 3-jaw chuck DK11-160 mm / D4- Face plate 200 mm / D4, according to DIN 55029- Fixed steady rest - passage diameter max. 60 mm- Follow-on steady rest - passage diameter max. 60 mm- Clamping plate 250 mm- Quadruple tool holder- Shaft fixing device- Protection device for tool holder- Slip clutch- Micrometer longitudinal stop- Coolant device- Extendable chip tray- Frequency converter- Foot pedal with brake function according to CE- Splash guard- Thread gauge- LED machine light- Digital speed display- Reducing sleeve- Change g ...

turning length: 750 mmturning diameter: 310 mmturning diameter over slide rest: 175 mmspindle bore: 32,0 mmtailstock quill taper MT: 3 MKturning speeds: 85 - 2200 U/minbed width: 200 mmtotal power requirement: 2.2 kWweight of the machine ca.: 710 kgrange L-W-H: 1884 x 717 x 1262 mm New price ~ 23.000 euros from a training workshop ()Furnishing:- Spindle speed continuously adjustable in 2x switching stages- TOS 3-jaw lathe chuck Ø 160 mm, with spare jaws & chuck key- NEWALL digital display, front left- MULTIFIX steel holder with inserts- Movable tailstock- live center, incl. quick-action drill chuck- digital speed display- Change gears- Foot/spindle brake all technical data:- Turning diameter over bed 310 mm- Distance between centers 750 mm- Spindle bore 32 mm- Turning diameter over cross slide 175 mm- bed width 200 mm- Spindle mount / DIN55027 5- Spindle taper 4.5 M- Spindle speed infin ...

turning length: 600 mmturning diameter over bed: 360 mmturning diameter over slide rest: 190 mmbed width: 295 mmnumber of spindle speeds: 45 - 2240 U/min.spindle bore: 33,0 mmtailstock quill taper MT: MK 3 feed: Längs 0,02-0,8 mm/Ufeed: Quer 0,0125-0,5 mm/Utotal power requirement: 5,5 kWweight of the machine ca.: 1900 kgrange L-W-H: 2050 x 950 x 1280 mm Refurbished and repainted in 2013 Costs around 16.000 eurosFurnishing:- WNW NILES 3-jaw chuck Ø 200 mm- Multifix steel holder size B with inserts- revolving center points- chuck key- Movable tailstock- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Merkez yüksekliği: 230 mm, yatak / çapraz kızak üzerinde dönüş çapı: 460 mm / 270 mm, mil deliği: 62 mm, merkezler arasındaki mesafe: 1000 mm, diş açma aralığı inç: 4-80 TPI. Makine, dijital bir ekranla donatıldı. Yerinde inceleme mümkündür.

turning length: 850 mmturning diameter: 400 mmswing diameter over bed slide: 245 mmspindle bore: 52.0 mmturning speeds: 45 - 1800 U/minbed width: 260 mmspindle taper: DIN 55029 D 1-5taper in tailstock: 3 MKquill travel: 120 mmtotal power requirement: 3.0 / 4.5 kWweight of the machine ca.: 1255 kgrange L-W-H: 1900 x 1000 x 1610 mmEquipment:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-200 mm / D5- Clamping disk 320 mm- Fixed steady rest - passage diameter max. 130 mm- Follow-on steady rest - passage diameter max. 100 mm- Coolant system- Quick-change tool holder with 4 inserts- Protective device for quick-change tool holder- Micrometer longitudinal stop- Slip clutch- Motor with magnetic brake in accordance with CE standard- Initial filling with Shell Tellus 46- Extendable chip tray- LED machine light- Change gears- Reduction sleeve- 2 centering points- Chip rear wall-  ...

turning length: 500 mmturning diameter over bed: 297 mmturning diameter over slide rest: 160 mmspindle bore: 36.0 mmtool adaptor: DIN 55022 Gr. 5quill:: 3 MKquill travel: 90.0 mmturning speeds: 30 - 3550 U/minmotor speeds:: 1410 / 2830 U/mintotal power requirement: 3.3 kWvoltage: 380 Vweight of the machine ca.: 620 kg.range L-W-H: 1420 x 700 x 1200 mm from a vocational school - very good condition () regularly receive a WEILER factory service particularly suitable for medium-precision turned partsEquipment:- robust lead/pull spindle lathe- KLOPFER four-jaw chuck Ø 140 mm- KLOPFER three-jaw chuck Ø 140 mm- collet holder with lots of collets- foldable lathe chuck guard- chuck key- MULTIFIX steel holder A, with 3x new inserts- movable tailstock- adjustable bed stop- control panel, front left- automatic feeds for face and top support- pole-changing drive motor- machine base frame, with cab ...

turning length: 1500 mmturning diameter: 420 mmswing diameter over bed slide: 255 mmturning dia. in gap: 580 mmspindle bore: 52.0 mmturning speeds: 45 - 1800 U/minbed width: 250 mmspindle taper: DIN 55029 D 1-6taper in tailstock: 4 MKquill travel: 140 mmtotal power requirement: 3.0 / 4.5 kWweight of the machine ca.: 1400 kgrange L-W-H: 2570 x 900 x 1600 mmEquipment:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck DK11-200 mm / D6- Clamping disk 350 mm- Fixed steady rest - passage diameter max. 135 mm- Follow-on steady rest - passage diameter max. 65 mm- Coolant system- Quadruple tool holder- Protective device for quadruple tool holder- Micrometer longitudinal stop- Slip clutch- Turret stop with fine adjustment- Thread gauge- Motor with magnetic brake according to CE standard- Foot pedal with brake function according to CE- Initial filling with Shell Tellus 46- LED machine l ...

turning length: 1500 mmturning diameter: 460 mmswing diameter over bed slide: 270 mmturning dia. in gap: 690 mmspindle bore: 80.0 mmturning speeds: 25 - 1700 U/minbed width: 300 mmspindle taper: DIN 55029 D 1-8taper in tailstock: 4 MKquill travel: 130 mmtotal power requirement: 5.5 kWweight of the machine ca.: 1845 kg.range L-W-H: 2750 x 1080 x 1600 mmScope of delivery:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-250 mm / D8- Clamping disk 450 mm- Coolant system- Initial filling with Shell Tellus 46- Fixed steady rest - passage diameter max. 150 mm- Follow-on steady rest - passage diameter max. 110 mm- Quick-change tool holder with 4 inserts- Protective device for quick-change tool holder- Motor with magnetic brake according to CE standard- Foot pedal with brake function according to CE- Slip clutch- Rapid traverse lengthwise and facewise- Change gears- 2 centering ...

turning length: 1500 mmturning diameter: 560 mmturning diameter over slide: 350 mmturning speeds: 25-220/220-1500 U/minswing diameter over bed slide: 350 mmturning dia. in gap: 785 mmquill travel: 185 mmspindle bore: 105,0 mmengine output: 7,5 kWspindle taper: DIN 55029 D 1-8quill:: 5 MKweight of the machine ca.: 2420 kg.range L-W-H: 2840 x 1150 x 1610 mmEquipment:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-315 mm / D8- Fixed steady rest - passage diameter max. 180 mm- Follow-on steady rest - passage diameter max. 120 mm- Foot pedal with brake function according to CE- Protective device for quick-change tool holder- LED machine light- Initial filling with Shell Tellus 46- Clamping disk 450 mm- 2 centering points- Frequency converter- Digital speed display- Slip clutch- Rapid traverse longitudinal and planar- Coolant system- Quick-change tool holder with 4 inserts-  ...

turning length: 3000 mmturning diameter: 660 mmturning dia. in gap: 870 mmturning diameter over slide: 420 mmturning speeds: 36 - 1600 U/minquill:: 5 MKquill travel: 150 mmspindle bore: 105,0 mmengine output: 7,5 kWspindle taper: DIN 55029 D 1-8weight of the machine ca.: 3990 kg.dimensions: 4500 x 1280 x 1650 mmScope of delivery- Slip clutch- Rapid traverse longitudinal and planar- LED machine light- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-315 mm / D8- Clamping disk 630 mm- Fixed steady rest - passage diameter max. 250 mm- Follow-on steady rest - passage diameter max. 110 mm- 1 centering point / 1 follow-on punch point- Motor with magnetic brake in accordance with CE standard- Foot pedal with brake function in accordance with CE- Initial filling with Shell Tellus 46- Coolant system- Quick-change tool holder with 4 inserts- Protective device for quick-change tool  ...

turning length: 1500 mmturning diameter: 410 mmswing diameter over bed slide: 255 mmturning dia. in gap: 580 mmspindle bore: 52,0 mmturning speeds: 30 - 3000 U/minbed width: 250 mmspindle taper: 55029 D 1-6taper in tailstock: 4 MKquill travel: 120 mmtotal power requirement: 5,5 kWweight of the machine ca.: 1400 kg.range L-W-H: 2530 x 1000 x 1450 mmScope of delivery- 3-axis digital display ES-12 V with LCD display- 3-jaw steel chuck PO3-200 mm / D6- Clamping disk 350 mm- Fixed steady rest - passage diameter max. 135 mm- Follow-on steady rest - passage diameter max. 65 mm- Foot pedal with brake function according to CE- Quadruple tool holder- Protective device for quadruple tool holder- Micrometer longitudinal stop- Turret stop with fine adjustment- Frequency converter- Initial filling with Shell Tellus 46- Coolant system- Slip clutch- Thread gauge- LED machine light- Change gears- Reducin ...

turning length: 1500 mmturning diameter: 560 mmturning diameter over slide: 350 mmturning speeds: 25 - 1600 U/minswing diameter over bed slide: 350 mmturning dia. in gap: 785 mmquill travel: 180 mmspindle bore: 105,0 mmengine output: 7,5 kWspindle taper: DIN 55029 D 1-8quill:: 5 MKweight of the machine ca.: 2.370 kg.range L-W-H: 2.840 x 1.150 x 1.460 mmScope of delivery:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-315 mm / D8- Clamping disk 450 mm- Fixed steady rest - passage diameter max. 180 mm- Follow-on steady rest - passage diameter max. 120 mm- 2 centering points- Initial filling with Shell Tellus 46- Motor with magnetic brake in accordance with CE standard- Foot pedal with brake function in accordance with CE- Coolant system- Quick-change tool holder with 4 inserts- Protective device for quick-change tool holder- Slip clutch- LED machine light- Change gears-  ...

turning length: 1000 mmturning diameter: 420 mmswing diameter over bed slide: 255 mmturning dia. in gap: 580 mmspindle bore: 52.0 mmturning speeds: 45 - 1800 U/minbed width: 250 mmspindle taper: DIN 55029 D 1-6taper in tailstock: 4 MKquill travel: 140 mmtotal power requirement: 3.0 / 4.5 kWweight of the machine ca.: 1220 kgrange L-W-H: 2070 x 900 x 1600 mmEquipment:- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck DK11-200 mm / D6- Clamping disk 350 mm- Fixed steady rest - passage diameter max. 135 mm- Follow-on steady rest - passage diameter max. 65 mm- Coolant system- Quadruple tool holder- Protective device for quadruple tool holder- Micrometer longitudinal stop- Slip clutch- Turret stop with fine adjustment- Thread gauge- Motor with magnetic brake according to CE standard- Foot pedal with brake function according to CE- Initial filling with Shell Tellus 46- LED machine l ...

Mazak Integrex 200 Y, 20 takım konumu, x,y,z = 530,140,1065. 30 kW iş mili motoru, 35-4500 rpm, ayna boyutu 210 mm, açık delik çapı 61 mm, güç altında

turning diameter: 750 mmturning length: 1520 mmcontrol: FANUC 18i TB turning diameter over slide: 540 mmchucking diameter: 8 spindle nose: A2 #6 spindle passage: 76 mmspindle turning speed - stepless: 5000 U/minspindle drive: 22/18,5 kWmilling spindle: milling spindle drive: 18,5 /15 kWmilling head speed: 12000 U/minx-axis: 565 mmz-axis: 1550 mmy-axis: +/- 85 mmb-axis: 0,001 °total power requirement: 56,7 kVAweight of the machine ca.: 13,8 tdimensions of the machine ca.: 5,9 x 2,5 x 2,8 mEquipped with:- FANUC Series 18i TB CNC control- Main & counter spindle- IKZ 20 bar- Tool magazine with 40 spaces- 3-jaw chuckThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 6 mm, 2600 mm

Freze mili ile tek kolonlu dikey torna tezgahı (VTL) CKD Blansko SKSJ-1A 2024'te modernize edildi Siemens Sinumerik 828D Yüz plakası çapı: 6.300 mm Ön yüz plakası yükü: maksimum 125.000 kg Dönüş çapı (ortaya): maksimum 8.000 mm Tornalama çapı (çevresel): maks. 16.000 mm İş parçası yüksekliği: maksimum 2.600 mm Piston dikey hareketi: Z 2.000 mm Tabla tahrik gücü: 92 kW Tabla hızları: maks. 20 rpm. C ekseni: 0.001 derece Freze mili tahrik gücü: 15 kW Freze mili hızları: maksimum 1.000 rpm İle donatılmış: Makine 2024 yılında modernize edildi. Yeni CNC kontrolü Siemens 828D. Siemens bileşenlerine sahip yeni kontrol kabini. Yeni bilyalı vidalar. Akslar için yeni dişli kutuları. 6 uzantılı hidrostatik tabla. Ortaya dönüş çapı maksimum 8000 mm. Tornalama çapı (çevre birimi) maks. 16.0 ...

Torna Magdeburg M160 GS 4 BJ 2003

Base machine CTX 200E with driven tools, C-axis and 1x back working. Includes DATAPILOT software package TurnPlus, cooling unit for control cabinet, hinge belt chip conveyor, discharge height: 1100mm including coolant tank, tool holder set for universal disc turret with tool holders for external machining, boring bar holders, tools with cylindrical shank holders, sealing plugs, reducing sleeves. Bar gripper, axial complete, workpiece pick-up device, tool spindles 3x axial for drilling/milling/tapping, 1x radial for drilling/milling/tapping, 1x for saw blades, collet chuck complete for main spindle, collet chuck complete for counter spindle, 17x DIN collets 173E round Ø 3-40mm, 2x DIN collets 173E, hex SW 7 and 12mm, 2x DIN collets 173E, square SW 8mm. Bar loading magazine IEMCA BOSS 542/32, guide channel set LW 13, additionally for IEMCA BOSS 542, 13x guide jaws for bar loading magazine ...

Klaaßen SDM15-5 torna işleme merkezi, Sunduğumuz üst torna tezgahı, temel konfigürasyonda aşağıdakilere sahiptir Teknik parametreler: ▪ SDM 4-5 CNC 4 Panel Yataklı Hassas Torna Tezgahı - Z-hareketi (uzunlamasına kayma)= 5.000 mm (TAE3 ile 6.000) X-hareketi (yüz kızağı enine)= 1.000 mm Y ekseni (dikey hareket)= 350 mm Maksimum iş parçası = 1.500 mm Yüzey kızağı üzerindeki sirkülasyon çapı = 1.500 mm - Merkez genişliği = 4.500 mm (TAE3 ile 5.500) ▪ 4 şeritli uç torna tezgahı olarak tasarlanmış CNC makinesi, tam geçişli Çerçeveler ve üst yapılar - - - Çapraz kızaklar ve yüz kızakları, çap aralığını yanal olarak sınırlar torna yatağı üzerinde düzenleme. Sonuç olarak, eşlik eden yoktur Yüz kızağı/alet taşıyıcısının üzerinde çap kısıtlaması. Çapraz kaydırma ünitesi ...

turning diameter over bed: 600 mmturning diameter over slide rest: 400 mmturning length: 1000 mmturning diameter in the gap: 850 mmturning speeds: 15 - 810 U/mincentre height: 300 mmspindle bore: 56 mmtotal power requirement: 9,0 KWweight of the machine ca.: 2,9 tdimensions of the machine ca.: 2,8 x 1,45 x 1,65 mCenter lathe- Forkardt 3-jaw chuck F 315- Single-jaw tool post- Steady rest- Live center- Chuck guard, limit switch monitored- Chip trayThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Nominal akım: 16A, nominal sigorta akımı: 16A, kontrol voltajı: 24V, dönme hızı: 63-4500 / dak, bağlı yük: 2.5 / 3kW, kontrol paneli: RATIONAL, ağırlık: 1.05t. Dijital göstergeli: hassas konum okuma için rasyonel 3 eksenli ekran (X, Y, Z), mesnet: diş açma için değiştirme dişlilerine sahip geleneksel tahrik, punta: el çarkı ile manuel olarak hareket ettirilebilir, destek: üst sürgü ve çapraz sürgü, manuel olarak çalıştırılabilir, acil durdurma ve çalıştırma elemanları. Yerinde inceleme mümkündür.

Yapım yılı 2017 İşletmeye Alma 06-2017 Kontrol Mazatrol Pürüzsüz X 5 eksenli eş zamanlı işleme Döner Çap 658 Milimetre tornalama uzunluğu 1.519 mm Seyahat X ekseni: 615 mm Y ekseni: 250 mm Z ekseni: 1.585 mm G ekseni: 1.574 mm B ekseni -30 ila 210 Hızlı travers X/Y/Z/W 50/40/50/30 m/dk Ana iş mili Tahrik gücü: 30 kW iş mili hızı 4.000 rpm C ekseni çubuk geçişi: 80 mm Alt iş mili Tahrik gücü: 26 kW iş mili hızı 4.000 rpm C ekseni Freze mili Tahrik gücü: 24 kW (yağ-hava yağlama) iş mili hızı: 12.000 rpm B ekseni: 0,0001 Capto C6 Takım magazini / ATC 72 takım pozisyonu takım çapı: 90/125 mm takım uzunluğu: 400 mm araç ağırlığı: 12 kg Özel ekipman Mayfran Consep 2000 II Talaş Konveyörü, Çift Anahtarlamalı Filtre Hazırlık IKZ 70 bar 70 bar yüksek basınç pompası, 7 bas� ...

Kontrol Mazatrol Pürüzsüz X 5 eksenli eş zamanlı işleme Döner Çap 658 Milimetre tornalama uzunluğu 1.519 mm Seyahat X ekseni: 615 mm Y ekseni: 250 mm Z ekseni: 1.585 mm G ekseni: 1.574 mm B ekseni -30 ila 210 Hızlı travers X/Y/Z/W 50/40/50/30 m/dk Ana iş mili Tahrik gücü: 30 kW iş mili hızı 4.000 rpm C ekseni çubuk geçişi: 80 mm Alt iş mili Tahrik gücü: 26 kW iş mili hızı 4.000 rpm C ekseni Freze mili Tahrik gücü: 22 kW iş mili hızı: 12.000 rpm B ekseni: 0,0001 Capto C6 Takım magazini / ATC 72 takım pozisyonu takım çapı: 90/125 mm takım uzunluğu: 400 mm araç ağırlığı: 12 kg Özel ekipman Knoll Talaş Konveyörü Kağıt bantlı filtreli Knoll soğutma sistemi Hazırlık IKZ 70 bar 70 bar yüksek basınç pompası, 7 basınç kademesi Üst taret üzerinde hava üfleme cihazı Freze mili ...

Kontrol Mazatrol Pürüzsüz X 5 eksenli eş zamanlı işleme Döner Çap 658 Milimetre tornalama uzunluğu 1.519 mm Seyahat X ekseni: 615 mm Y ekseni: 250 mm Z ekseni: 1.585 mm G ekseni: 1.574 mm B ekseni -30 ila 210 Hızlı travers X/Y/Z/W 50/40/50/30 m/dk Ana iş mili Tahrik gücü: 30 kW iş mili hızı 4.000 rpm C ekseni çubuk geçişi: 80 mm Alt iş mili Tahrik gücü: 26 kW iş mili hızı 4.000 rpm C ekseni Freze mili Tahrik gücü: 22 kW iş mili hızı: 12.000 rpm B ekseni: 0,0001 Capto C6 Takım magazini / ATC 72 takım pozisyonu takım çapı: 90/125 mm takım uzunluğu: 400 mm araç ağırlığı: 12 kg Özel ekipman Knoll Talaş Konveyörü Kağıt bantlı filtreli Knoll soğutma sistemi Hazırlık IKZ 70 bar 70 bar yüksek basınç pompası, 7 basınç kademesi Üst taret üzerinde hava üfleme cihazı Freze mili ...

yatak üzerinde dönüş çapı: 330 mmKızak dayanağı üzerinde dönüş çapı: 200 mmTornalama uzunluğu: 800 mmtoplam güç gereksinimi: 3 kWmakinenin ağırlığı yaklaşık: 800 kgMakinenin boyutları yaklaşık: 1,9x0,7x1,2 mdönüş hızı aralığı: 24-2800 U/dakBu reklamın verileri, LogoTech oHG'nin yazılım çözümü olan ModulMWS ile oluşturulmuştur.

Genel Üretici firma: Spinner Türü: TTC300 65SMMCY Kontrol: Siemens 840D SL ShopTurn Yapım Yılı: 2015 Hareket X1 / X2 / Z / Y: 180 / 110 / 450 / +40-40 mm Hızlı travers X1 / X2 / Z / Y: 15 / 15 / 15 / 24 m/dak Torna Mili 1 Hız: 4.000 rpm Ayna boyutu: 250 mm Mil geçişi: 52 mm İş mili gücü S1 / S6: 21 / 27 kW Tork S1 / S6: 201 / 258 Nm Torna mili 2 Hız: 7.000 rpm Ayna boyutu: 130 mm İş mili gücü S1 / S3: 6 / 8,5 kW Tork S1 / S3: 49 / 68 nm Tabanca Takım sayısı: 12 + 12 (BMT45) Döner Takımlar: 12+12 (BMT45) Hız: 6.000 rpm Güç S1 / S3: 2,3 / 3,5 kW Tork S1 / S3: 7 / 11 nm Boyutlar ve ağırlık Boyutlar: 2,700 mm x 1,900 mm x 2,165 mm Ağırlık: 5.100 kg Koşul Durum: Kullanılmış Fonksiyonel: Test edilmiş ve tamamen işlevsel Dahil olan diğer ekipman ve aksesuarlar: IKZ 50 bar bantlı filtre sistemli Parça Tutuculu ...

X1-/ X3-axis: 180mm, X2-axis: 180mm, Y1-/ Y3-axis: ±45mm, Z1-/ Z3-axis: 704mm, Z2-axis: 620mm, E2-axis: 720mm, rapid traverse X, Y, Z-axis: 30m/min, spindle 1: max. speed: 5000/min, spindle bore: 65mm, chuck diameter: 210mm, spindle 2: max. speed: 7000/min, spindle bore: 42mm, max. chuck diameter: 140mm, spindle nose diameter: 110mm, max. chuck jaw weight: 1.25kg, number of stations: 2x12, number of driven tool stations: 2x12, max. speed: 8000/min, power S3 25%: 4.3kW, torque S3 25%: 13.6Nm. Length: 2880mm, width: 2130mm, height: 1990mm, weight: 7.5t, operating hours: 16,597.7h. Including bar feeder Top Automazioni X-FILES S, year of manufacture 2020, 4x tool holders, straight, left-right square mount, external coolant, 4x machine interface: BT45A, 1x milling head 90°/BMT 45 Spinner, angled milling head/ BMT45/ ESX-25 right and left twin-spindle, Spinner flat coupling, ER25 max. speed: ...

CNC torna tezgahı DMG MORI NLX 2500 SY/700 DMG MORI M730 UM MAPPS CELOS DENETLEYICI ILE Yapım Yılı: 2019 Dönüş çapı: 356 mm X'te Hareket: 260 mm Z'de Seyahat: 795 mm Y'de hareket: +- 50 mm Mil çapı: 91 mm Ana iş mili hız aralığı: 4000 rpm Tahrik edilen aletlerin hız aralığı: 10000 rpm Aşağıdaki aksesuarlarla: İç aydınlatmalı çalışma odası kapısı 12 tahrikli istasyonlu 12 vitesli taret C Ekseni, Y Ekseni Dokunmatik Prob ( Marposs ) Ayak pedallı NC punta Takım ön ayarlayıcı kılavuzu ( HS ) 3 çeneli ayna hidrolik Kitagawa BB 254, ayak pedallı (HS) Ana iş mili için çeşitli çene setleri ( HS ) 3 adet Elektrikli El Aletleri Doğrudan yer değiştirme ölçüm sistemi X, Y, Z ekseni Sinyal lambası 4 renk Konveyör Kompakt şişe sistemli yüksek basınçlı soğutma sistemi 70 bar / 700 l tank Kullanma talimatlar�

max. swing diameter over bed: 620 mmmax. turning diameter: 270 mmMax. Turning length: 510 mmcontrol: Siemens Sinumerik 828D spindle bore: 62 mmtravel -x axis: 200 mmtravel -z axis: 560 mmtravel -y axis: 110 (+/- 55) mmno. of tools in turret: 16 xtool taper: BMT 45 - - - - - Main spindle - - - - -: - - - - - -number of spindle speeds: 4.500 U/minchucking diameter: 200 mm--- Subspindle ---: - - - - - -number of spindle speeds: 6.000 U/minchucking diameter: 150 mmCNC Turning- and Milling Center | MTEvo - T22SY equipped with a turret for driven tools, Y-axis, and sub-spindle.Scope of delivery / Accessories: - 7x static holders- 1x vertical driven tool- 1x horizontal driven toolThe machine has accumulated only 1,656 spindle hours on the main spindle and 542 spindle hours on the sub-spindle.The machine is in a very well-maintained, like-new condition.For additional equipment information please ...
