23 WALDRICH COBURG satılık ikinci el makine

Key data: 10000 , 3950 , 2500

Büyük parçaların yanı sıra birçok küçük iş parçasını işlemek için kullanılır. Makine 2021 yılında modernize edilmiştir CNC FANUC kontrol rafı tipi X ekseni 10000 mm Y ekseni 3950 mm Z ekseni 2500 mm Tabla uzunluğu 8000 mm Tabla genişliği 2800 mm Masadaki maksimum yük 60000 kg iş mili hızı 2000 rpm ------------------- Uzunluk x genişlik x yükseklik 171000.0 × 93300.0 × 67600.0 Ağırlık 150000 kg Sağlam bir çalışma masası ve tahrip edilemez bileşenlerle donatılmış makine, frezeleme, delme ve kılavuz çekme gibi görevlerin en yüksek hassasiyetle gerçekleştirilmesine olanak tanıyarak çok çeşitli endüstrilerde maksimum proses optimizasyonunu garanti eder.

x-travel: 17700 mm y-travel: 4755 mm z-travel: 800 mm milling width: 3450 mm distance table - vertical milling spindle: 3682 mm table height over floor: 500 mm spindle diameter in front bearing: 200 mm turning speed range: 12 - 450 U/min tool taper: ISO 60 axial adjustment of the spindle slide: 800 mm creep feed: 5 und 50 mm/min feed stepless: 10 - 3000 mm/min cross adjustment of cross beam milling head: 4745 rapid traverse: 2 m/min creep feed: 3 und 30 mm/min feed stepless: 6 - 2000 mm/min rapid traverse: 10 m/min creep feed: 3 und 30 mm/min feed stepless: 6 - 2000 mm/min vertical adjustment of cross beam: 3682 mm rapid traverse: 1,5 m/min creep feed: 1,25 und 12,5 mm/min feed stepless: 5 - 1500 mm/min table-size: 17800x2800 mm column daylight: 3600 mm Control: SIEMENS 840 C table load: 50.000/100.000 kg drive of main spindle: 100 kW total power requirement: 170 kW weight of the machine ...

max. ram stroke: 600 mm throat: ca. 400 – 800 mm table diameter: - mm : 320 mm total power requirement: - kW weight of the machine ca.: 8 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 9700 mm y-travel: 3500 mm z-travel: 640 mm w-axis: 3000 mm Control: Siemens type: 840D PL spindle diameter: 200 mm Spindle capacity: 85 Kw surface area: 9000x2800 mm Table load: 40000 kg column daylight: 3400 mm chip conveyor: coolant: high speed spindle taper ISO: 50 total power requirement: kW weight of the machine ca.: 193,8 t dimensions of the machine ca.: 22,4x10,2x8,2 m Retrofit 2009 Steep taper ISO 60 DIN 2079 Speed 12-450 rpm Milling heads: 1x WF 680/450 1x WFU 180/350 1x WFU 70/300 1x 550 mm extension for WFKs The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in se ...

x-travel: 6300 mm y-travel: 2200 mm workpiece height: 1835 mm Table area: 6000x1835 mm Rest: 2 Side head: 2 number of T-slots: 7 T-slot - distance: 240 mm T-slot - width: 28 mm bed length: 14650 mm column daylight: 2075 mm feed: 5-60 m/min workpiece weight: 15000 kg total power requirement: kW weight of the machine ca.: 55 t dimensions of the machine ca.: 14,65x4,37x4,05 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look fo ...

throat: 645 mm workpiece height max.: 550 mm stroke: 360 mm table diameter: 650 mm milling-head swivable +/-: 15/80 no. of strokes: 100 Hub/min total power requirement: 6 kW weight of the machine ca.: 4,3 t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

throat: 1410 mm workpiece height max.: 1150 mm stroke: 1400 mm table diameter: 1400 mm milling-head swivable +/-: 10 ram - range of adjustment: 750 mm pulling power: 50000 N workpiece weight: 10000 kg Ram stroke speed: 30 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data f ...

table diameter: 900 mm Table load: 3000 kg Daylight: 580 stroke: 95-800 mm total power requirement: kW weight of the machine ca.: 8 t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

2 makine + 7 paletli depolama + 2 kurulum istasyonu olan Karusel Torna ve Frezeleme İşleme Merkezi Her biri birden fazla torna ve frezeleme ünitesi (diken/yatay) Capto C6 veya HSK100 ile donatılmıştır Üretici: Waldrich Coburg Yıl: 2005 1 x MultiTurn 1500 FM, 1 x Multitec 2000 Kontrol: Siemens Daha fazlasını buradan bulabilirsiniz - / Bizimle şu adresten iletişime geçin:

WALDRICH COBURG 20-10 FP 280 ist ein Portalfräswerk, ausgelegt für hochpräzise Bearbeitung, große Genauigkeit und Zuverlässigkeit. Tisch 8000×2800 mm, 11 T-Nuten 36H8 (250 mm Abstand); Verfahrwege X 9000 mm, Y 2950 mm, Z 1250 mm, W 2200 mm; Durchgang 3200 mm; max. Abstand Tisch-Spindel 2806 mm; Tischbelastung 64000 kg. Spindelaufnahme 60 ISO, 16 Stufen 20–600 t/min; Spindelmotor 100 kW, Drehmoment 13000 Nm; Vorschübe X/Y 5–3000 mm/min, Z 5–2000 mm/min, W 5–750 mm/min; Anschluss 3x 380 V 50 Hz; Abmessungen ca. 21000×7800×6622 mm. Optionale Ausstattung: 90° Aufnahme, schmale 90° Aufnahme, vertikale Verlängerung, kippbarer Aufsatz. Eignet sich für enge Toleranzen; typisch in Automotive, Luftfahrt, Werkzeugmaschinenbau und schwerer Industrie. Technische Daten ohne Gewähr

WALDRICH COBURG 0-15 SNC-Q 2017 X ist eine Flachschleifmaschine, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Arbeitsvermögen: Tischlänge 2000 mm, Tischbreite 1100 mm. Hauptspezifikationen: Universalschleifkopf U15; Anschluss 50 Hz, 3x 400 V. Entwickelt für enge Toleranzen; typische Einsatzbereiche: Automotive, Luftfahrt, Werkzeugmaschinen und Medizintechnik. Technische Daten ohne Gewähr

İnv. Sayı : 9154 Tip: 17-10 FP NC/5 Yapımcı: Waldrich Coburg Oluşturulma tarihi: 1985, GO 2011 Parametreler: İşletim sistemi: Sinumerik 840 Masa uzunluğu: 5000 mm Masa genişliği: 2500 mm Maksimum iş parçası ağırlığı: 60000 kg Ağırlık: 125000 kg Soğutucu sıvı makinenin mil kısmından dışarı sızıyor. Makinede 1997/2008/2011 yıllarında GO işlemleri yapıldı.

Bu 5 eksenli WALDRICH COBURG 17-10 FP NC/5, 1985 yılında üretildi ve son olarak 2011'de yenilendi. Maksimum 60 ton iş parçası ağırlığı ve 2.500 mm x 5.000 mm ölçüsünde önemli bir masa boyutuna sahiptir. Makine, operasyonlarda hassasiyet sağlayan Sinumerik 840 kontrol sistemiyle donatılmıştır. Yüksek kaliteli frezeleme yetenekleri arıyorsanız, satışımızda bulunan WALDRICH COBURG 17-10 FP NC/5 gantry frezeleme makinesini düşünün. Daha fazla bilgi için bizimle iletişime geçin.

X-Ekseni 10.000 mm Y ekseni 1.500 mm Yükseklik yüksekliği 1.850 mm Masa boyutu 10.200 x 1.500 mm Boyut L=22.67m, W=3.97m, H=3.95m Kilo yaklaşır. 58.000 kg

Waldrich Coburg 17 S-10 FP 300 NC / 5 m – CNC Gantry Milling Machine Machine: 17-10 FP 300 NC / 5 m Serial Number: 2.8304.06 Original Year of Manufacture: 1983 In 2016, it was comprehensively overhauled and modernized by the manufacturer Waldrich Coburg. The machine is equipped with a modern Siemens SINUMERIK 840D sl control system and is ideally suited for heavy-duty machining of large and complex workpieces in machine, tool, mold, and power plant construction. The delivery includes a Universal Fork Milling Head USP 300 C 350 with B-axis as well as an additional Angle Milling Head WFU 500 SZ 400 F17 , ensuring versatile machining capabilities for demanding milling tasks. The machine features a modern full protective enclosure, coolant system, chip conveyor technology, and extensive technical documentation including circuit diagrams and overhaul documentation. The system  ...

Upper support, cross support, cross table, cross slide table -Upper support comes from a Waldrich Coburg portal milling machine type: 12 D 3232-550 HL -Table surface: mm -Travel: x 350 mm/y 220 mm -Dimensions: 1380/1000/H800 mm -Weight: 800 kg

x-travel: 6000 mm y-travel: 3500 mm z-travel: 1500 mm Control: 840 D table load: 12 t height over floor: 6300 mm table dimension - longitudinal: 5000 mm table dimension - cross: 2500 mm tool change unit: 200- fach weight of tools max.: 30 kg tool taper: HSK A 100 tool diameter: 250 mm tool length - max.: 500 mm spindle speed:: 5 -6000 U / min c-axis: -10 bis 370 ° b-axis: 5 bis -95 ° column daylight: 3000 mm total power requirement: kW weight of the machine ca.: 161 t dimensions of the machine ca.: 20,5 x 11 x 6,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter: 25-90 mm threading length: 3000 mm thread pitch: 2-16 mm total power requirement: 25 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 8400 mm grinding width: 1450 mm workpiece height: 1250 mm surface area: 8000 x 1250 mm table height over floor: 920 mm distance between columns: 1470 mm workpiece weight max.: 59700 kg weight of the machine ca.: 59,7 t dimensions of the machine ca.: 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW The data for this ad was created with ModulMWS - the  ...

x-travel: 6000 mm y-travel: 3500 mm z-travel: 1500 mm total power requirement: kW weight of the machine ca.: 161 t dimensions of the machine ca.: m x-travel 6000 mm y-travel 3500 mm z-travel 1500 mm CNC control 840 D Table load 12 t Table dimensions - lengthways 5000 mm Table dimensions - crossways 2500 mm ATC tool changing device 200-pos. Tool weight max. 30 kg Tool holder HSK A 100 Tool diameter 250 mm Tool length - max. 500 mm Spindle speed: 5 - 6000 rpm C-axis -10 to 370 deg B-axis 5 to -95 deg Column distance 3000 mm Machine weight approx. 161 t Space requirement approx. 20.5 x 11 x 6.3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Kızaklı taşlama makinesi Waldrich Coburg -30-10 S 3640 Kontrol: Siemens 840D Yapım Yılı: 2012 Seyahat: X ekseni 8.825 mm Y ekseni 3.010 mm Z ekseni 2.500 mm Tabla uzunluğu 8.000 mm Tabla genişliği 1.800 mm Masa yükü: 18.000 kg Besleme X ekseni: 1 - 45.000 mm/dak Besleme Z ekseni: 100 - 3.000 mm/dak 110 Derece Eğimli / 2500 Rpm / 7,5 kW Üniversal Taşlama Kafası S10 Dikey Taşlama Kafası S30, 600 x 150 / 930 Rpm / 22 kW Makinenin solunda ve sağında çift SIEMENS 840D kontrol cihazı Makineye / yüke / sıkmaya kolay erişim için otomatik kapılar (4x) 18000 kg çalışma yüküne sahip hidrolik tabla motoru KNOLL HL650/4000 filtreleme sistemi yeni 2023 Çeşitli taşlama taşları Büyük Paket Yedek Parçaları / Bilyalı Vidalar / Kapaklar 2012 yılında 1,5 milyon Euro'ya renovasyon

Bu 3 eksenli WALDRICH COBURG 30-15 S 2525 öğütme makinesi 1991 yılında üretilmiştir. 11.500 x 6.610 x 5.170 mm boyutlarında sağlam bir yapıya ve yaklaşık 45.800 kg ağırlığına sahiptir. 11.000 kg'a kadar iş parçalarını taşıyabilecek kapasitede, 3.500 mm öğütme uzunluğu ve 1.450 mm öğütme genişliği sunar. Yüksek kaliteli öğütme yetenekleri arıyorsanız, satışımızda bulunan WALDRICH COBURG 30-15 S 2525 makinesini düşünün. Daha fazla bilgi için bizimle iletişime geçin.

- Kılavuz / Sürgü / Yüzey Taşlama Makinesi - 110 derece eğimli S10 evrensel taşlama başı / 2500 rpm / 7,5 kW- 600 x 150 / 930 rpm / 22 kW gücünde dikey taşlama başlığı S30 - Çift SIEMENS 840D Kontrol paneli Sol ve sağ taraf makinesi - KNOLL HL650/4000 filtrasyon sistemi yeni 2023- Kolay makine / yükleme / kelepçe girişi için otomatik kapılar (4x) - 18000 Kg iş yükü ile hidrolik masa tahriki- 2012'de 1,5 milyon EUR için yeniden inşa edildi- Büyük paket flanchlar ve taşlar- Büyük paket yedek parçalar / bilyalı vidalar / ölçüm / koruma kapaklar�
