Edm makineleri VOLLMER QXD 200

Universal machine for eroding and grinding various PCD tools up to 250 mm in diameter and 200 mm in length in production and service. Accessories: Full enclosure Measuring probe for complete measurement of the tools Workpiece carrier adaptation A-axis from SK 50 to HSK 63 A Loader for up to 6 eroding disk sets (tool changer) Alphanumeric keyboard Standard programs for measuring, eroding Cooling and cleaning device for dielectric Automatic fire extinguishing device Extraction N183 1 exchange element 1 flushing set 1 measuring mandrel 1 mounting flange for rotating electrodes, X axis travel: 440 mm, B-axis: +/- 15°, Y axis travel: 876 mm, Z-axis travel: 420 mm, E-axis swivel range: 210°, A-axis rotation range: 360°, workpiece carrier base: SK 50, workpiece length max.: 200 mm, Workpiece diameter max.: 250 mm, workpiece weight: 15 kg, Connected load approx.: 6.7 kW 400V/50 Hz, Weight approx: 7000 kg, Dimensions W x D x H =: 1987 x 3141 x 2275 mm, colour: RAL 7047 Telegray 4/ Color RAL 7045 Telegray 1
seller offer No. resale M02083
