presler kullanılmış satılık (1,671)

CONTROLS  PLC SCHNEIDER PRESS DESIGN  drive system: eccentric / crank   number of slide actions: 11   feedstock transport direction: left to right PRESS FORCES  total force (nominal): 66 toSLIDE  slide force: 6 to  stroke: 114 mmSLIDE (MECHAN. PRESS)  variable speed: yes   stroke rate (min.): 40 /min  stroke rate (max.): 130 /min  main drive power: 7.5 kWSTRIP-FEEDER  feeder type: roll feeder TRANSFER SYSTEM  distance between tools, stroke X fixed: 82 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 2875 mm  space requirements -front/back-: 1500 mm  total height: 2900 mm  total weight approx.: 7500 kgATTACHMENTS (PRESSES)  safety guard / safety door: yes   2-hand engagement: yes   noise protection cabin: yes   acc. to actual accident protection regulation: yes Specifications:Number of stations: 12 (11+1)Capacity per ram: 6 tonsMaximum str ...

CONTROLS  PC controller BECKHOFF PRESS DESIGN  number of slide actions: 13 SLIDE  slide force: 3 to  stroke: 60 mm  stroke rate (max.): 210 /minSLIDE (MECHAN. PRESS)  slide adjustment: 6 mm  variable speed: yes   stroke rate (min.): 70 /min  stroke rate (max.): 210 /min  main drive power: 4 kWDIMENSIONS / WEIGHTS  space requirements -left/right-: 2300 mm  space requirements -front/back-: 1000 mm  total height: 1900 mm  total weight approx.: 4000 kg

PRESS DESIGN  drive system: hydraulic   frame design: C-frame, single sided   table cushion: yes   opening in table: yes PRESS FORCES  total force (nominal): 100 toPRESS TABLE  table surface (left-right): 710 mm  table surface (front-back): 560 mmSLIDE  slide force: 100 to  table surface (left-right): 560 mm  table surface (front-back): 450 mm  spigot hole diameter: 50 mm  stroke: 320 mm  thickness of bolster plate: 150 mmSLIDE (HYDR. PRESS)  approximation velocity max.: 340 mm/s  working velocity max.: 32 mm/s  return velocity max.: 330 mm/sSLIDE EJECTOR / CUSHION  nominal force: 2 to  stroke: 40 mmDIE CUSHION (TABLE CUSHION)  cushion force: 10 to  stroke: 80 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 455 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 300 mm  sheet thickness max.: 20 mm  spee ...

Key data: 40 t, 1030 mm

Satışta, seri sac metal parça şekillendirme için birinci el robot sistemine sahip otomatik bir pres freni bulunmaktadır. Pres Freni 2019 BYSTRONIC Xpert 40/1030 Robot 2019 KUKA KR10R 1100 sixx Özellikler Pres Freni - Basım gücü: 400kN (40t) - Çalışma uzunluğu: 1030mm - Kontrol: ByVision Robot - Maksimum nominal yük kapasitesi: 11kg - Erişim hattı: 1100mm - Akslar: 6 dingli - Pozisyon tekrarlanabilirliği: 0.02mm - CE sertifikalı güvenlik modülleri Özellik -lerini - Entegre 6 eksenli endüstriyel robotlu tam otomatik bükme hücresi - birinci elden - Boyutlar (LxWxH): yaklaşık 3.25m x 2.8m x 2.5m - 22 inç Full HD dokunmatik ekranlı ByVision Bending kontrol terminali Makine durumu - Çalışma saatleri: 7.724 saat - Döngü sayacı: 310.212 - Tam servis geçmişi, düzenli denetimler - Teknik olarak mükemmel durum - Fonksiyo ...

CONTROLS  PC controller BECKHOFF Offer for servicesof complete Overhaul of a Customer-Owned Fineblanking Press FEINTOOL GKP 160Scope of Overhaul• Complete disassembly into individual components• Inspection of all parts, including crack testing of critical components• Overhaul of the drive system, new motors• Reworking and precise alignment of all guideways• Complete overhaul of the hydraulic cylinders• Overhaul of the clamping tables• Installation of a new hydraulic unit• Renewal of the pneumatic system• Renewal of the electrical systemModernisation / Retrofit• Combined table• Servo feed systems• Central lubrication system• RAZIOL band lubrication• New brake/clutch unit• BECKHOFF PC-based control system with touch panel• PILZ safety control system• Implementation of CE conformityNotes• Special options and customer-specific extensions can be integrate ...

CONTROLS  PC controller BECKHOFF PRESS DESIGN  drive system: knuckle-joint SLIDE  total force (nominal): 160 to  stroke: 60 mm  stroke rate (max.): 70 /minCOUNTER RAM  nominal force: 40 to  stroke: 14 mmV-RING  nominal force: 50 to  stroke: 10 mmTOOL DIMENSIONS  lower table (left-right): 480 mm  lower table (front-back): 520 mm  upper table (left-right): 480 mm  upper table (front-back): 520 mm  shut height max.: 314 mm  ram adjustment: 80 mm  distance between columns (H-frame): 500 mm  passline opening (free passage in side columns): 220 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 210 mm  sheet thickness max.: 6 mm  feeding step max.: 999.9 mm  sheet length min: 2000 mm  pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into individual parts findings of all compon ...

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 50 toPRESS TABLE  table surface (left-right): 700 mm  table surface (front-back): 450 mmSLIDE  table surface (left-right): 440 mm  table surface (front-back): 360 mm  spigot hole diameter: 40 mm  stroke: 90 mm  stroke rate (max.): 70 /minSLIDE (MECHAN. PRESS)  slide adjustment: 70 mm  stroke min.: 0 mm  stroke max.: 90 mm  main drive power: 3 kWTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 300 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 700 mm  space requirements -front/back-: 1295 mm  total height: 2360 mm  total weight approx.: 3000 kg

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 45 toPRESS TABLE  table surface (left-right): 700 mm  table surface (front-back): 440 mm  opening in bed (diameter): 40 mmSLIDE  table surface (left-right): 410 mm  table surface (front-back): 280 mm  stroke rate (max.): 110 /minSLIDE (MECHAN. PRESS)  slide adjustment: 65 mm  stroke min.: 0 mm  stroke max.: 90 mm  main drive power: 5.5 kWTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 380 mm  distance between columns (H-frame): 360 mmATTACHMENTS (PRESSES)  2-hand engagement: yes   foot engagement: yes   European CE standards: yes

CONTROLS  conventional PRESS DESIGN  drive system: eccentric / crank   frame design: C-frame, single sided PRESS FORCES  total force (nominal): 100 toSLIDE  slide force: 100 to  stroke rate (max.): 72 /minSLIDE (MECHAN. PRESS)  slide adjustment: 80 mm  stroke adjustment: yes   stroke min.: 8 mm  stroke max.: 112 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 407 mmATTACHMENTS (PRESSES)  2-hand engagement: yes for safe tools only

CONTROLS  PLC SIEMENS S7 300 PRESS DESIGN  drive system: hydraulic PRESS FORCES  total force (nominal): 800 toPRESS TABLE  table surface (left-right): 2600 mm  table surface (front-back): 2000 mm  height above floor level: 540 mmSLIDE  stroke: 900 mmSLIDE (HYDR. PRESS)  approximation velocity max.: 460 mm/s  working velocity min.: 25 mm/s  working velocity max.: 44 mm/s  return velocity max.: 460 mm/sTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 1700 mmELECTRICAL SPECIFICATIONS  total power consumption: 180 kWDIMENSIONS / WEIGHTS  total weight approx.: 95000 kgATTACHMENTS (PRESSES)  press automation: yes   gripper transfer system: yes   acc. to actual accident protection regulation: yes   European CE standards: yes Complete hot forming line consisting of: Hydraulic press NEFF 800 to. Ruhstrat furnace system:- Natural gas heat ...

Basınç: 63 tSütunlar arasındaki mesafe: 360 mmstrok: 400 mmMakinenin ağırlığı ca.: 4 tMakinenin boyutları ca.: 1.8x1.6x2.7 m

CONTROLS  PLC SIEMENS S7 PRESS DESIGN  drive system: link drive   feedstock transport direction: left to right SLIDE  total force (nominal): 80 to  stroke: 50 mm  stroke rate (max.): 80 /minCOUNTER RAM  nominal force: 22 to  stroke: 8 mmV-RING  nominal force: 25 to  stroke: 15 mmTOOL DIMENSIONS  lower table (left-right): 420 mm  lower table (front-back): 420 mm  upper table (left-right): 420 mm  upper table (front-back): 420 mm  shut height max.: 220 mm  ram adjustment: 80 mm  distance between columns (H-frame): 450 mm  passline opening (free passage in side columns): 200 mmOVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 180 mm  sheet thickness max.: 5 mm  feed velocity max.: 999 m/minSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 180 mm  sheet thickness max.: 5 mm  feeding step max.: 999 mm  sheet length min: 1350 mm ...

CONTROLS  PC controller BECKHOFF C 6140 PRESS DESIGN  drive system: hydraulic   frame design: H-frame, monoblock   quick die change system: yes   feedstock transport direction: left to right SLIDE  total force (nominal): 410 to  stroke: 200 mmSLIDE (HYDR. PRESS)  approximation velocity max.: 200 mm/s  working velocity min.: 8 mm/s  working velocity max.: 80 mm/s  return velocity max.: 150 mm/sCOUNTER RAM  nominal force: 120 to  stroke: 40 mmV-RING  nominal force: 250 to  stroke: 40 mmTOOL DIMENSIONS  lower table (left-right): 820 mm  lower table (front-back): 1250 mm  upper table (left-right): 820 mm  upper table (front-back): 1250 mm  shut height max.: 410 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 450 mm  sheet thickness max.: 16 mm  feeding step min.: 1 mm  feeding step max.: 999.9 mm  speed max.: 48 m/min  nomina ...

basınç: X tmasa boyutu: 550x390 mmboğaz: 550 mmmanyetik plaka boyutu: 250x100 mmmakinenin ağırlığı ca.: 0.25 tDaha fazla detay

CONTROLS  PC controller BECKHOFF PRESS DESIGN  drive system: knuckle-joint SLIDE  total force (nominal): 250 to  stroke: 61 mm  stroke rate (max.): 60 /minCOUNTER RAM  nominal force: 75 to  stroke: 15 mmV-RING  nominal force: 75 to  stroke: 13 mmTOOL DIMENSIONS  lower table (left-right): 540 mm  lower table (front-back): 540 mm  upper table (left-right): 540 mm  upper table (front-back): 540 mm  shut height max.: 320 mm  ram adjustment: 145 mm  distance between columns (H-frame): 560 mm  passline opening (free passage in side columns): 270 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 250 mm  sheet thickness max.: 10 mm  feeding step max.: 999.99 mm  sheet length min: 1900 mm  pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into individual parts findings of all com ...

CONTROLS  PLC SIEMENS S7 300 PRESS DESIGN  drive system: hydraulic PRESS FORCES  total force (nominal): 800 toPRESS TABLE  table surface (left-right): 2000 mm  table surface (front-back): 2000 mm  height above floor level: 700 mmSLIDE  table surface (left-right): 2000 mm  table surface (front-back): 2000 mm  stroke: 900 mmSLIDE (HYDR. PRESS)  approximation velocity max.: 400 mm/s  working velocity min.: 5 mm/s  working velocity max.: 160 mm/s  return velocity max.: 300 mm/sTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 1700 mm  distance between columns (H-frame): 2100 mmELECTRICAL SPECIFICATIONS  total power consumption: 370 kW  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 81000 kgATTACHMENTS (PRESSES)  press automation: yes   gripper transfer system: yes   acc. to actual acci ...

CONTROLS  PLC SIEMENS S7-400 PRESS DESIGN  drive system: hydraulic   number of suspensions: 1   slide ejectors / cushion: no   table cushion: no   opening in table: no   feedstock transport direction: back-front PRESS FORCES  total force (nominal): 1000 toPRESS TABLE  table surface (left-right): 2066 mm  table surface (front-back): 2000 mm  height above floor level: 630 mmSLIDE  stroke: 900 mmSLIDE (HYDR. PRESS)  approximation velocity max.: 600 mm/s  working velocity min.: 15 mm/s  working velocity max.: 40 mm/s  return velocity max.: 390 mm/s  return force: 100 toTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 1710 mm  distance table - slide max.: 1700 mmELECTRICAL SPECIFICATIONS  total power consumption: 160 kW  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  height above floor level: 6500 mm  t ...

PRESS DESIGN  drive system: knuckle-joint   frame design: H-frame, monoblock SLIDE  total force (nominal): 160 to  stroke: 60 mm  stroke rate (max.): 72 /minCOUNTER RAM  nominal force: 40 to  stroke: 60 mmV-RING  nominal force: 50 to  stroke: 13 mmTOOL DIMENSIONS  lower table (left-right): 470 mm  lower table (front-back): 470 mm  upper table (left-right): 500 mm  upper table (front-back): 470 mm  shut height max.: 277 mm  ram adjustment: 80 mm  distance between columns (H-frame): 500 mm  passline opening (free passage in side columns): 220 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 210 mm  sheet thickness max.: 6 mm  feeding step max.: 180 mmELECTRICAL SPECIFICATIONS  mains voltage: 380 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1950 mm  space requirements -front/back-: 1800 mm  to ...

kg cinsinden basınç: 6000

Teknik verilerBalık: 4,5 kNTable yüzey:Uzunluk: 170 mmWidth: 145 mmDoğuk: 100 mmTüm boyutlar makine:Uzunluk: 380 mmSağlık: 300 mmHeight: 700 mm

Özellikler Üretici: Otto Schröder İnme: 160mm elle ayarlanabilir Stand arasındaki mesafe: 800mm Geçit: 250mm Destek tablosu: 800mm, 4 oluklu kısmi daire 400mm oluk boyutu 25x75mm Delik: Masa merkezi 70mm Masa yüksekliği: 835mm Boyutlar: UxGxY 110x900x2200mm

2004 yılında üretilen mekanik damgalama presi. Bu AIDA NC2-1600(2) 160 ton baskı gücü ve 200 mm sürme vuruşuna sahiptir. Kaydırma alanı 1500 x 580 mm ve destek alanı 2040 x 760 mm'dir. Yüksek kaliteli damgala yetenekleri arıyorsanız, satışta olan AIDA NC2-1600(2) makinesini düşünün. Daha fazla bilgi için bizimle iletişime geçin.

Key data: 200 t, 80 mm

İnv. Sayı: 9036 Tip: 200 T Yapımcı: ROSS Oluşturulma tarihi: 2003 Parametreler: Kontrol sistemi: DIMECO MCU 24 Sıkıştırma kuvveti: 200 t Masa uzunluğu: 2100 mm Masa genişliği: 1000 mm Strok: 80 mm Ram ayarı: 150 mm Makine ağırlığı: 36700 kg

Makine teknik olarak iyi durumda, önceden anlaşmadan sonra test edilebilir. - Nominal şekillendirme kuvveti: 120 t Çalışma uzunluğu: 3106 mm CNC kontrolü Delem (grafik 2D programlama) Bükülme dizisi ve çarpışma algısının otomatik hesaplanması 2× manuel ayarlanabilir stop parmakları CNC elektromotor yükseklik ayarı arka ölçü (R ekseni) CNC elektrikle kontrol edilen masa saptırma Üst alet adaptörü ROLLERI Ekipman ve aksesuarlar: - Ön koruyucu cihaz (eğilebilir kapı) - Arka koruma cihazı (sürgülü kapı) - 1× serbestçe hareket ettirilebilir iki elle / Ayak kontrolü - CE beyanını içeren çalışma talimatlar�

Bu HIDROLIKSAN PH4C 200T hidrolik pres 2015 yılında üretilmiştir. 200 tonluk sağlam bir pres gücüne ve 1800x1400 mm ölçülerinde büyük bir masaya sahiptir; bu da çeşitli presleme uygulamaları için idealdir. Bu HIDROLIKSAN PH4C 200T hidrolik presi satın alma fırsatını değerlendirin. Daha fazla bilgi için bizimle iletişime geçin.

Bu Sangiacomo T.450 RCE Bükme makinesi 2018 yılında İtalya'da üretildi ve 7062 üretim saati var. Siemens Simatic HMI kontrol ünitesi ile donatılmıştır. Makinenin baskı gücü 4500 kN, mükemmel durumda ve çalışma saatleri düşüktür.

Env. Sayı : 948 Türü: LVH 2500 Yapımcı: ŽĎAS Oluşturuldu: 1961 Parametre: Derinlik: 1800 mm Genişlik: 3450 mm Yerden yükseklik: 4650 mm Ağırlık: 85 000 kg Gerilim: 220 / 380 V Şebeke frekansı: 50 Hz İş gücü: 2500 t Vuruş sayısı: 20/dak Asansörlerin yüksekliği: 500 mm Tabladan minimum piston mesafesi: 900 mm Tabladan maksimum piston mesafesi: 1400 mm Masa yüzeyi: 1050 x 1400 mm Piston alanı: 1050 x 1200mm

Env. Sayı : 946 Türü: LKO 315 Yapımcı: ŠMERAL Oluşturuldu: 1956 Parametre: Uzunluk: 3600 mm Genişlik: 1750 mm Yükseklik: 4600 mm Piston stroku: 180 mm Vuruş sayısı: 60 / dak Ağırlık: 17 000 kg Güç gereksinimi: 25 kW Gerilim: 380 V Frekans: 50 Hz

Env. Sayı : 8718 Türü: LDC 250 Yapımcı: SMERAL Oluşturuldu: 1987 Parametre: Basınç kuvveti: 245 t Maksimum strok hızı üst tabla: 38 1/dak Koçun ayarlanması: 120 mm Ram stroku: 200 mm Makine ağırlığı: 29800 kg

Key data: 250 t

Env. Numara : 8652 Türü: ZHS 250 Yapımcı: ŽDB Hydraulika Üretildi: 2000 Parametre: Basınç kuvveti: 250 t Tabla uzunluğu: 3500 mm Tabla genişliği: 1200 mm İnme: 700 mm Ram boyutları: 3500 x 1200 mm Çalışma hızı: 13-60 mm/sn Makine yüksekliği: 6000 mm Makine uzunluğu: 3000 mm Makine genişliği: 5000 mm Makine ağırlığı: 60000 kg
