testere ahşap çalışma kullanılmış satılık (1,057)

sliding carriage length: 3200 mm; cutting width with rip fence: 1200 mm; cutting width at the cross cut: 3450 mm; Schnittiefe: scoring unit: yes; height adjustment: manual / crank; tilt adjustment: manual / crank; rip fence adjustment: manual; display saw blade tilt: digital; display saw blade height: -; display rip fence: scala; display at the cross cut: Scala; saw blade diameter: speeds: 3200 / 4200 / 5000 U/min; motor power: 5 kW; motor brake: yes - automatically; suction connection: 80 mm and120 mm; machine length: 3350mm; machine width: 1800 mm; weight:

sliding table length: 1500 mm; cutting width at the fence: 700 mm; cutting width at the cross cut: 2200 mm; cutting depth: 100 mm; scoring unit: no; adjustment sawblade height: manuell / Kurbel; adjustment sawblade tilting: manuell / Kurbel; adjustment fence: manuell; read out sawblade tilting: Digital; read out cutting height: -; read out fence: Scala; read out crosscut: Scala; saw blade diameter: 315 mm; number of speeds: 1; motorpower: 4 kW; motor brake: ja - automatisch; suction connection: 80 mm und 120 mm; machine length: 3000 mm; machine width: 1700 mm; weight: 900 kg;

sliding table length: 3200 mm; cutting width at the fence: 1350 mm; cutting width at the cross cut: 3200 mm; cutting depth: 125 mm; scoring unit: ja; sawblade diameter: electric; tilting adjustment sawblade: electric; adjustment fence: manuell; readout sawblade tilting: Scala; read out sawblade height: -; read out fence: Scala; read out crosscut stop: Scala; sawblade diameter: 400mm; number of speeds: 3000 / 4000 / 5000 U/min; motor power: 7 kW; motor brake: yes, automatic; suction connection: 80mm und 120mm; machine length: 3400mm; machine width: 2000mm; weight: 900kg;

roll diameter: 600 mm; cutting width: 580mm; table tilting: yes; belt speed: motor power: 2,2 kW; motor brake: yes / manual; suction connection: 100mm; machine length: 120mm; machine width: 800mm; machine hight: 2015mm; weight: 200kg;

Depth of cut at 90°: 200 mm; Depth of cut at 45°: 140 mm; Cutting width at 90°: 420 mm; Cutting width at 45°: 295 mm; Miter range horizontal: 45° -90° -25°; Miter range vertically: 60° -90° -30°; Sawblade diameter: 520 mm; rpm: 2800 U/min; Motor: 5 kW; motor brake: yes; suction plant diameter: 100 mm; weight: 490 kg; suitable for: wood, PVC, alucross-cut and mitre saw with maximum cutting height of 200mmstable grey cast iron constructionprecise ball bearing guide of the tool slide on hardened and ground steel shaftsmanual saw feedfast mitre adjustment up to 25° horizontal and 30° verticalreadjustable fixed stops at 90° and 45°lower saw blade protection can be connected to extraction systemmachine mounted on mobile machine base with 1.5 m long roller conveyors left and rightleft side with scale and stop slide

Optimierungskappsäge Fabrikat: SALVADOR Typ: Supercut 300 Neumaschine Optimierende Säge zum senken der Kosten Die extrem schnelle optimierende Kappsäge Supercut 300 kann das Produktionssystem eines Unternehmens revolutionieren. Äußerst robust Die Struktur besteht aus dickem, verstärktem und lackiertem Stahl. Das Einlaufband ist synchronisiert und wird vom gleichen Motor wie auch die Vorschubwalzen angetrieben. Einzigartiges duales und solides oberes und unteres Vorschubsystem. Die obere Antriebseinheit besteht aus 3 Zahnrädern und 6 Laufrollen (3 Paare), die von oben auf das Holz drücken. Das Anheben und Absenken der Zahnräder wird direkt von der rechnergestützten numerischen Steuerung gesteuert. Schnell Optimierung sowohl in Hinblick auf die Schnelligkeit als auch den Gesamtablauf, und das bei einer Maschine, die durch ihre kompakten Abmessungen  ...

Vertical panel saw Brand: Putsch Type: SVP 950 M New machine Description: The SVP 950 M is a vertical saw for cutting panels in vertical and horizontal direction. The frame of the saw is completely welded and it has a working table for the workpieces which consists of aluminium fences with plastic inserts. To prevent a contact with the saw blade while doing horizontal cuts, the frame is equipped with an automatic moving support. The lower workpiece supports consist of aluminium and have lowerable transport rolls. The saw beam and the saw unit can be adjusted and moved manually. Therefore the saw beam can be fixed at 6 vertical sawing positions. The simple shift of the saw head is possible because of an ergocnomical formed handle. Standard equipment: - Electric driven, automatic moving support - Swivable central support for small workpieces (length approx. 4680 mm) - 4 gr ...

Halbautomatische Kappsäge Fabr.: Salvador Typ: SUPERPUSH 150 Neumaschine Superpush 150 ist das Einstiegsmodel für den Holzzuschnitt mit Optimierungsfunktion. Die Maschine wurde als direkte technologische Weiterentwicklung der herkömmlichen Sägemethoden entwickelt und kann sowohl die Produktivität als auch die Holzausbeute steigern. ÄUSSERST ROBUST Die Struktur besteht aus dickem, verstärktem und lackiertem Stahl. Horizontale Auflagefläche mit beweglichem Schutz, damit das Werkstück leichter eingelegt werden kann. Schlitten mit Messanschlag und Schubfunktion. Lineareinheit mit Zahnriemen mit Stahleinlagen und Gleitschiene mit Linearlagern. Horizontale, durchgehende Werkstückablage mit einer Breite von 300 mm. TECHNOLOGISCH INNOVATIV Elektronisches System bestehend aus einem Touchscreen mit integrierter CNC. Software für Linux-Umgebung mit kundenspezifische ...

Crosscut saw for miter cuts Brand: SALVADOR Type: Superangle 600 New machine High performance crosscut saw with rotary table for miter cuts -70° / + 70°. Max. Saw blade diameter 600 mm Saw cross section at straight cut: 30 x 100 mm resp. 310 x 160 mm Saw cross section at 45°: 260 x 100 mm resp. 220 x 160 mm Saw cross section at 70°: 120 x 100 mm resp. 100 x 160 mm Rotary table guided on precision bearings Optical system with laser light barrier for detection of the wood length and Luminescence reader to detect the markings. No manual adjustments for wood thickness Powerful Windows software for easy and safe operation

Vertical panel-sizing saw Brand: Putsch Type: SVP 145 M New machine Description: The SVP 145 M is a vertical panel saw for cutting panels in vertical and horizontal direction. The frame of the saw is completely welded and has a support grid for the workpieces to be processed, consisting of aluminium strips and plastic inserts. The automatic grid displacement ensures that the saw blade does not hit the support bars during horizontal cuts. The lower workpiece supports consist of aluminium soles and plastic inserts. For the easy movement of the workpieces, the machine is equipped with retractable transport rollers. The saw beam and the saw carriage can be moved and adjusted by hand, the saw beam can be fixed in 5 vertical sawing positions for this purpose. The comfortable insertion and removal of the saw head is ensured by an ergonomically shaped handle. Standard equipment: - El ...

Sliding table saw Brand: Panhans Type: 680 100 New machine Technical data: Trolley length 3200 mm Cutting length 3400 mm Cutting height max. 155 mm at 90 ° 105 mm at 46 ° Cut width Width stop 1030 mm Saw blade max. Ø 450 mm Saw blade under table retractable Ø 400 mm Table size cast table top 1200 x 655 mm Table extension plus. 750 x 655 mm Table extension 1200 x 655 mm Table height +/- 20 mm 900 mm Main saw blade speed 3000/4000/5000/6000 rpm Net weight approx. 1051 kg Technical description: Solid German mechanical engineering For trimming, cutting to length, formatting, miter cutting, etc. Dimensionally stable and self-supporting machine body manufactured as a stable frame welded construction from thick-walled steel profiles, laser-processed sheet steel parts and mechanically processed The torsion-resistant and finely planed cast table top is built on the  ...

Panel sizing saw, vertical Brand: Putsch Type: SVP 420 M New machine Description: The SVP 420 M is a vertical panel saw practical for cutting panels vertically and horizontally. The saw frame is completely welded and has an attachment grate for the workpieces, consisting of aluminum strips and plastic inserts. The automatic grate movement ensures that the saw blade does not hit the contact strips in the case of horizontal cuts. The lower workpiece supports consist of aluminum soles and plastic supports. For simple movement of the workpieces, the machine is equipped with retractable transport rollers. The saw beam and saw carriage can be moved and adjusted by hand, the saw beam can be fixed at 5 vertical sawing positions. The comfortable entry and exit of the saw head is ensured by an ergonomically shaped handle. Standard features: - electrically driven, automatic shift gate ...
