diğer gıda makineleri kullanılmış satılık (926)

Tetra Pak ​​​​​​​​​​​​Tetra Therm Aseptic VTIS line with Tetra Alex TA400 homogeniser. Aseptic processing unit for continuous UHT treatment with direct steam injection. Mainly for heat-sensitive low-acid products such as milk, enriched milk, cream, soy milk, formulated dairy products, ice-cream mix, dairy desserts as well as ESL (extended shelf life) products. Previously used in a milk factory in Europe., The unit is fully automated to safeguard the aseptic status while in production. The operation can be divided into four steps:, - Pre-sterilization, - Production, - Aseptic intermediate cleaning (AIC), - Cleaning in place (CIP), Before production can start, it is necessary to sterilize the aseptic area by circulating pressurized hot water. After sterilization, the unit is cooled down to production temperature. Finally, sterile water is circulated through the prod ...

The Fristam FKL 150 is a rotary positive displacement pump which can handle dairy products (e.g., yoghurt, quark, curd and butter), solids (e.g., cherries and olives), slurries, pastes, and a variety of liquids. The rotors are balanced. The diameter of the shaft is up to 25% larger than other manufacturers shafts and is solid made of 316L stainless steel. The FKL 150 is a close clearance PD pump to be designed for True CIP (Clean In Place). Duo - twin wing stainless steel lobes. Nominal displacement: 0,981 liter per revolution. Maximum nominal capacity: 35,3 m3/h. Inlet connection: 3. Outlet connection: 3. Maximum product pressure: 20 bar (300 psi). Maximum pump speed: 600 rpm. The pump is used in a food factory for product pumping. The current motor with this pump is 7,5 kW - 1.445 rpm - 400 V - 50 Hz - 14,8 A and the lobe speed is converted to 147 rpm, which results in a capacity of 8, ...

Industrial plate heat exchanger, previously used for ice water cooling applications. Designed for efficient heat transfer between two liquid media, making it suitable for cooling and other temperature-control processes in the dairy, food and beverage industries. The heat exchanger is configured with one section containing 131 plates, providing a total internal volume of approximately 157 liters. The unit is designed for a maximum allowable operating pressure of 16,0 bar and a maximum allowable temperature of 110°C. The connection configuration consists of two header connections at the top and two follower connections, one positioned at the top and one at the bottom., Type of Machine: Plate Heat Exchanger, Volume: 157 Liter, Number of sections: 1x, Number of plates: 131x, Max. working pressure: 16 bar, Premissible Temperature: 110 °C

Industrial plate heat exchanger, previously used for ice water cooling applications. Designed for efficient heat transfer between two liquid media, making it suitable for cooling and other temperature-control processes in the dairy, food and beverage industries. The heat exchanger is configured with one section containing 140 plates, providing a total internal volume of approximately 34 liters. The unit is designed for a maximum allowable operating pressure of 6,0 bar and a maximum allowable temperature of 110°C. The connection configuration consists of two header connections at the top and two follower connections at the top., Type of Machine: Plate Heat Exchanger, Volume: 34 Liter, Number of sections: 1x, Number of plates: 140x, Max. working pressure: 6,0 bar, Premissible Temperature: 110 °C

Serviced Continuous Butter Making Machine (CBM) equipped with a new Rittal control panel with simple and user-friendly controls. Stainless Steel frame execution. The machine is designed for the continuous production of sweet butter from cultured and / or sweet cream and is suitable for hygienic dairy processing applications. The CBM has a butter production capacity of approximately 3.000 kg per hour and is designed for an input of approximately 6.000 litres of cultered or / and sweet cream per hour (38/42% fat, pH of 4,5/4,8 and infeed temperature ± 10 - 13 °C). Completely electrically driven; Churning cylinder / Beater I: 37 kW, Churning cylinder II: 3 kW and Squeezer / Working section: 11 kW., The machine is equipped with a new Rittal electrical control panel, incorporating simple and clearly arranged controls for the main machine functions. The control panel includes:, - 3 x Danfoss ...

This Tetra Pak, Tetra Alex Modified 30 (TAM30A/200BAR) Aseptic homogeniser is a 3-cylinder machine with a maximum design capacity up to 18.100 ltr/h @ 200 bar maximum pressure. The current capacity with the current motor is set on 16.500 liter per hour at 200 bar. The homogeniser is equipped with 2-stages with mushroom valve cylinders. Hydraulic valves for pressure setting on the front panel. Piston diameter: 63 mm. Piston stroke: 130 mm. Manometer. Motor: 110 kW - 400 V - 192 Amp - 50 Hz - 1487 rpm. Oil pumping system inside the machine. Stainless steel cladded., Additional features:, Excluding:, - Control panel., Type of Machine: Homogeniser, Capacity: 16.500 liter per hour, Stages: 2 stages, Max. Pressure: 200 bar, Valve cylinder: Mushroom valves, Piston diameter: 63 mm, Motor: 110 kW - 400 V - 192 Amp - 50 Hz - 1487 rpm, Dimensions: 275 x 190 x 130 cm, Weight: 3.700 kg

Filter system, clean air filter, fine filter, filter, compact filter, HEPA filter, filter cassette -Manufacturer: Filt Air, Air filter type GT4-13AE-YACO -Front frame dimensions: 1210 x 600 mm, see photo of the type plate -Connection: Ø 255 mm -Quantity: 1x air filter included -Dimensions: 1210/130/H600 mm -Weight: 16 kg

Serviced Continuous Butter Making Machine (CBM) equipped with a new Rittal control panel with simple and user-friendly controls. Stainless Steel frame execution. The machine is designed for the continuous production of sweet butter from cultured and / or sweet cream and is suitable for hygienic dairy processing applications. The CBM has a butter production capacity of approximately 750 kg per hour and is designed for an input of approximately 1,500 litres of cultered or / and sweet cream per hour (35/42% fat, pH of ± 4,8 and infeed temperature ± 8 - 13 °C). Completely electrically driven; Churning cylinder / Beater I: 11 kW, Churning cylinder II: 1,5 kW and Squeezer / Working section: 3,7 kW., The machine is equipped with a new Rittal electrical control panel, incorporating simple and clearly arranged controls for the main machine functions. The control panel includes:, - 3 x Danfoss  ...

Complete Karl Schnell GmbH & Co. KG, Germany processing line for the production of processed UHT cheese from natural cheese blocks. The complete processing line is designed for the continuous and efficient processing of natural cheese into a processed cheese product suitable for UHT processing and aseptic filling (ideal for IWS / Triangle and foil wrapped cheese packaging). The line combines the necessary processing equipment for cheese preparation, melting and resting to achieve a consistent final product quality. The line offers a flexible production capacity and is suitable for industrial-scale production of processed cheese products. Capacity of end product of the line: 200 - 750 kg/h output. Year of manufacturing of the complete line: 2011. Project number: AK09-2971. Processing line number: 09-164., The complete line exist out of the following machines:, A) Processed Cheese Blending ...
