Folyo makinesi HUGO BECK SERVO X 10
baskı makineler / basın sonrası: diğer
Counter: 1,200,000 units Cycle counter: 8,297,167 cycles Hour counter: 5,281 hours Equipment / Additional information: Machine consists of: 1 x Main feeder 1 x Opener 4 x Insert stations 1 x Wrapping system (10,000 cycles per hour) with side sealing 1 x CROSS STACKER RIMA Options: 1 x Friction ...
Üretici: HUGO BECK
model:SERVO X 10
Makine türü: Folyo makinesi
İlan No.: 170193582
miktar: 1
tarih: 16.09.2026
Üretim yılı: 2019
yer:
İsviçre
fiyat:
Fiyat öneriniz:
Stoktaki makine:Hayır
Seller-item-No.:40009.26
Counter: 1,200,000 units
Cycle counter: 8,297,167 cycles
Hour counter: 5,281 hours
Equipment / Additional information:
Machine consists of:
1 x Main feeder
1 x Opener
4 x Insert stations
1 x Wrapping system (10,000 cycles per hour) with side sealing
1 x CROSS STACKER RIMA
Options:
1 x Friction feeder
1 x Mosca inline coating unit
1 x 90° curve
1 x Videojet BX 6500
1 x Graftech server
TECHNICAL DATA
Product infeed: manual as standalone/automatic in line
Film: centre-folded and flat film, e.g. PE, PO, PP, bio films, recycled content films
Output: max. 10,000 cycles/h
Passage width: 10–450 mm
Passage height: max. 200 mm
Product length: min. 80 mm
Film width: max. 1,000 mm (flat film)
Film roll diameter: max. 350 mm
Control system: Siemens Sinamics D
Display: Siemens 9" TP 900 touchscreen
Electrical design: in accordance with VDE guidelines
Working height: adjustable from 850–950 mm
Cycle counter: 8,297,167 cycles
Hour counter: 5,281 hours
Equipment / Additional information:
Machine consists of:
1 x Main feeder
1 x Opener
4 x Insert stations
1 x Wrapping system (10,000 cycles per hour) with side sealing
1 x CROSS STACKER RIMA
Options:
1 x Friction feeder
1 x Mosca inline coating unit
1 x 90° curve
1 x Videojet BX 6500
1 x Graftech server
TECHNICAL DATA
Product infeed: manual as standalone/automatic in line
Film: centre-folded and flat film, e.g. PE, PO, PP, bio films, recycled content films
Output: max. 10,000 cycles/h
Passage width: 10–450 mm
Passage height: max. 200 mm
Product length: min. 80 mm
Film width: max. 1,000 mm (flat film)
Film roll diameter: max. 350 mm
Control system: Siemens Sinamics D
Display: Siemens 9" TP 900 touchscreen
Electrical design: in accordance with VDE guidelines
Working height: adjustable from 850–950 mm
