129 MORI SEIKI satılık ikinci el makine

MORI SEIKI NT6600 CNC ENTEGRE FREZE TORNALAMA MERKEZI CANLI FREZELEME YATAKIN ÜZERINDE MAKSIMUM SALLANIŞ: 42 inç MAKSIMUM IŞ PARÇASI ÇAPI: 42inch MAKSIMUM IŞ PARÇASI UZUNLUĞU: 239inch MAKSIMUM ÇUBUK ÇAPI: 6.4inch İŞ MİLİ DELIĞI: 7 inç X EKSENİ SEYAHAT: 41 inç Y ekseni SEYAHAT: 26 inç Z EKSENI SEYAHAT: 242 inç B EKSENI: +/- 120 DERECE. ANA IŞ MILI HIZI: 1500 RPM ANA IŞ MILI MOTORU: 40 HP FREZELEME MILI HIZI: 8000 RPM FREZE MILI MOTORU: 40 HP ELEKTRIK: 220V / 3P / 60Hz / 216A OAD (YAKLAŞIK): 490 inç X 182 inç X 169 inç YÜKSEK AĞIRLIK (YAKLAŞIK): 120.560 LBS ŞUNLARLA DONATILMIŞ: C EKSENİ YEKSEN B EKSENİ CANLI TAKIM/FREZELEME 20 inç CHUCK FS-31iA5 CNC KONTROLÜ 140 KONUMLU OTOMATİK TAKIM DEĞİŞTİRİCİ PROGRAMLANABİLİR BAGAJ STOĞU İŞ MILINDEN SOĞUTMA SIVISI (YÜKSEK BASINÇ) TALAŞ KONVEYÖRÜ Ek Kontrol Seçenekleri: ...

x-travel: 560 mm y-travel: 510 mm z-travel: 510 mm Control: MSC 502 distance spindle center to table: 50 - 650 mm distance Spindlenose and center of table: 100 - 610 mm Main spindle:: turning speed range - main spindle: max. 12.000 min/-1 power capacity - main spindel: 22 / 18,5 kW tool taper: MAS BT-40 spindle bearing diameter: 70 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiecediameter: 580 mm max. workpiece height: 650 mm b - axis: switching time: 90°: 2,5 sec change time of pallets: 6,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT-40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg change-time tool to tool: 1,5 sec change-time chip to chip: 3,7 sec feeds:: rapid traverse ( X / Y / Z ): 32 m/min feed speeds: 1 - 24.000 mm/min Tipp feed: 0 - 1.260 mm/m ...

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...

turning diameter:356 mm turning length:705 mm control:MSX 850 MAPPS II swing dia.:755 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 (+-50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min rapid traverse Y-axis:10 m/min Rapid travel B-axis (parts transfer subspindle):30 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:6000 1/min Spindle 2 power:11 / 7,5 kW turret stations / rotary tool stations:16 / 16 VDI 30 :5.5/5,5/3,7 kW speed of driven tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) High precision Turning and Milling Centre with Y-axis and sub spindle. Easy programming by MAPPS II Control.

x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"

x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

x-travel:800 mm y-travel:460 mm z-travel:510 mm total power requirement:20 kW weight of the machine ca.:8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough.

turning diameter: max. 420 mm turning length: 713 mm control: MSX 850 III MAPPS Mitsubishi swing over bed: 995 mm Swing dia. over traverse guideway: 825 mm max. turning diameter: 420 mm max. bar capacity: 90 mm Main spindle:: turning speed range - main spindle: max. 3.000 min/-1 power capacity - main spindel: 30 / 25 kW spindle nose: JIS A2-8 spindle bearing diameter: 160 mm spindle bore: 105 mm max. bar capacity: 90 mm C-Axis: 0,001 ° axis stroke:: x-axis: 280 mm z-axis: 820 mm turret:: Tooling: 12 Pos. Schank height for square tool: 25 mm Diameter of boring bar: 50 mm turret change time: 0,3 sec. Spindle speed - driven tool stations: max. 6.000 min -1 power capacity driven tool-stations: 5,5 / 3,7 kW feeds:: rapid traverse X-axis: 30 m/min rapid traverse Z-axis: 30 m/min rapid traverse C-axis: 300 min/-1 Tailstock:: tailstock: 734 mm diameter of quill: 110 mm taper of center: MK  ...

turning diameter: max. 356 mm turning length: 705 mm control: MSX 850 III MAPPS Mitsubishi greates pass round over bed: 923,8 mm Swing dia. over traverse guideway: 755 mm standard turning dia.: 275 mm Main spindle:: max. spindle speed: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bearing diameter: 140 mm spindle bore: 91 mm max. bar capacity: 80 mm chucking diameter: 305 mm C-Axis: 0,001 ° Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle nose: JIS A2-5 spindle bearing diameter: 85 mm spindle bore: 43 mm chucking diameter: 210 mm C-Axis: 0,001 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Shank diameter: 26 mm Drill shank diameter: 50 mm Spindle speed - driven tool stations: max. 6.000 min -1 turret change time: 0,25 sec. axis stroke:: x-a ...

dönme çapı: 430 mm torna uzunluğu: 519-525 mmkontrol: Mori seiki MSX-805 x ekseni: 230 mmz ekseni: 520 mm toplam güç gereksinimi: kW makinesinin ağırlığı ca.: 4100 kgMakinenin boyutları ca.: mBu reklam için veriler, LogoTech oHG'nin yazılım çözümü olan ModulMWS ile oluşturulmuştur.

x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT  ...

Model: Mori Seiki MV-653/50 (2000 yılı) Seyahat Aralığı (X/Y/Z): 1530 x 660 x 650 mm (60 inç x 26 inç x 25.6 inç) Masa Boyutu: 1700 x 660 mm (67 inç x 26 inç) Mil Konikliği: CAT 50 / BT 50 Mil Hızı: 6.000 RPM (Yüksek Tork) Motor Gücü: 22 kW (30 HP) ATC Kapasitesi: 30 İstasyon Makine Ağırlığı: 16.000 kg (35.270 lbs) Daha fazlasını buradan bulabilirsiniz - / Bizimle şu adresten iletişime geçin:

x-travel: 560 mm y-travel: 560 mm z-travel: 660 mm Control: M 730 BM MAPPS IV distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 70 - 730 mm Main spindle:: max. spindle speed: 12.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle diameter in front bearing: 80 mm pallet changer:: numbers of pallets: 2 pos. work height max.: 1.050 mm size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm Max. workpiece - hight: 900 mm B-Axis: 0,001 ° Indexing-time 90°: 1,3 sec change time of pallets: 8,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: SK 40 max. tool diameter: 70 mm max. tool-dia with free toolbox: 170 mm max. tool length: 450 mm max. tool weight: 8 kg change-time tool to tool: 0,9 sec change-time chip to chip: 2,8 - max. 9,9 sec feeds:: feed speeds: max. 60.000 mm/mi ...

x-travel: 560 mm y-travel: 560 mm z-travel: 660 mm Control: M 730 BM MAPPS IV distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 70 - 730 mm Main spindle:: max. spindle speed: 12.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle diameter in front bearing: 80 mm pallet changer:: numbers of pallets: 2 pos. work height max.: 1.050 mm size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm Max. workpiece - hight: 900 mm B-Axis: 0,001 ° Indexing-time 90°: 1,3 sec change time of pallets: 8,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: SK 40 max. tool diameter: 70 mm max. tool-dia with free toolbox: 170 mm max. tool length: 450 mm max. tool weight: 8 kg change-time tool to tool: 0,9 sec change-time chip to chip: 2,8 - max. 9,9 sec feeds:: feed speeds: max. 60.000 mm/mi ...

Turlama çapı: 370 mm torna uzunluğu: 424 mm kontrol: Fanuc toplam güç gereksinimi: makinenin kW ağırlığı ca.: makinenin boyutları ca.: mBu reklam için veri, LogoTech oHG'nin yazılım çözümü olan ModulMWS ile oluşturulmuştur.

turlama çapı: 190 mm dönüş uzunluğu: 235 mm. kontrol: FANUC/Mori MSX 501 mil dönüş hızı aralığı: 50-5000 U/mintaret başlığı: 2x 16 makinenin ağırlığı ca.: 7.5 tY- ve B- eksenlerÇeşitli aksesuarlar hakkında daha fazla detay www.marcels-maschinen.ch Bu reklamın verileri, LogoTech oHG'nin yazılım çözümü ModulMWS ile oluşturulmuştur.

turlama çapı: 190 mm dönüş uzunluğu: 235 mm. kontrol: FANUC/Mori MSX 501 mil dönüş hızı aralığı: 50-5000 U/mintaret başlığı: 2x 16 makinenin ağırlığı ca.: 7.5 tY- ve B- eksenlerÇeşitli aksesuarlar hakkında daha fazla detay www.marcels-maschinen.ch Bu reklamın verileri, LogoTech oHG'nin yazılım çözümü ModulMWS ile oluşturulmuştur.

dönme çapı: - mmturn uzunluğu: - mmcontrol: - : ohne Gewähr toplam güç gereksinimi: - makinenin kW ağırlığı ca.: makinenin 4 ölçüsü ca.: - mBu reklam için veri, LogoTech oHG'nin yazılım çözümü ModulMWS ile oluşturulmuştur.

turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...

turning diameter: 460 mm turning length: 795 mm control: MORI SEIKI M730 BM Swing diameter face slide: 590/360 mm spindle passage: 80 mm Traverse X/Z:: 260/795 mm Number of working hours: 19.552 h Cutting time: 10.704 h spindle drive: 18,5 kW total power requirement: 40 kVA weight of the machine ca.: 6,4 t dimensions of the machine ca.: 3.994 x 3.056 x 2.187 m Chip chuck Ø250 mm. Chuck sub-spindle Ø170 mm. Holder HAINBUCH chip conveyor suction Bar feeder Hydrafeed Multiservo mod MSV max. bar length 1,600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor:  ...

Bu 4 eksenli MORI SEIKI RL2500, 2003 yılında üretilmiştir. Maksimum 400 mm dönüş çapına sahiptir ve her biri 12 istasyonlu iki taret içerir; böylece verimli işleme yetenekleri sağlanır. Makine, Mori Seiki MAPPS MSX-501 kontrol ünitesi ile donatılmıştır ve 3500 rpm'lik mil hızına sahiptir. Yüksek kaliteli torna yetenekleri arıyorsanız, satışımızda olan MORI SEIKI RL2500 çok milli torna makinesini düşünün. Daha fazla bilgi için bizimle iletişime geçin.

CONTROLS   CNC controls MORI SEIKI MSC 500 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 560 mm   Y-axis travel: 410 mm   Z-axis travel: 460 mm TABLE   table surface (left-right): 900 mm   table surface (front-back): 450 mm   workpiece load (max): 300 kg SPINDLE / HEAD   spindle revolutions (min): 80 /min   spindle revolutions (max): 8000 /min   tool fixture: ISO BT 40 TOOL MAGAZINE   number of positions: 20 ELECTRICAL SPECIFICATIONS   mains power supply: 15.5 kVA DIMENSIONS / WEIGHTS   space requirements -left/right-: 2210 mm   space requirements -front/back-: 2242 mm   total height: 2723 mm   total weight approx.: 4200 kg

CONTROLS   CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   X-axis travel: 1300 mm   Y-axis travel: 1200 mm   Z-axis travel: 1100 mm TABLE   table surface (left-right): 800 mm   table surface (front-back): 800 mm   workpiece load (max): 2000 kg SPINDLE / HEAD   spindle revolutions (max): 0 /min   spindle revolutions (max): 6000 /min   tool fixture: ISO BT 50 AXIS DRIVES   rapid traverse: 42000 mm/min TOOL MAGAZINE   number of positions: 60 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 7400 mm   space requirements -front/back-: 4300 mm   total height: 3750 mm   total weight approx.: 23500 kg ATTACHMENTS   chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant att ...

CONTROLS   CNC controls MITSUBISHI M720BM BASIC FUNCTIONS   number of spindles: 2   number of turrets: 1   live positions: yes   number of c-axes: 2 WORKING RANGE TURNING   swing diameter (max): 700 mm   turning diameter (max): 350 mm MAIN SPINDLE   spindle revolutions (max): 4000 /min   spindle bore diameter: 90 mm   c-axis: yes X/Z SLIDE   - rotation speeds (max): 6000 /min TOOL MAGAZINE   number of positions: 24 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 7500 kg ATTACHMENTS (TURNING)   chip conveyor: yes   coolant unit: yes   hydraulic system: yes   European CE standards: yes Machine in a good condition The spindle guides need to be replaced. Machine equipment (1500.- CHF (below)): - 1x double face and longitudinal turning tool holder - 3x face and longitudinal turnin ...

CONTROLS   CNC controls FANUC 18 MB WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 900 mm   Y-axis travel: 800 mm   Z-axis travel: 980 mm   rotating range B-axis from: 0 °   rotating range B-axis up to: 360 ° TABLE   table surface (left-right): 630 mm   table surface (front-back): 630 mm   workpiece load (max): 1200 kg SPINDLE / HEAD   spindle type: horizontal   spindle revolutions (max): 10000 /min AXIS DRIVES   rapid traverse: 50000 mm/min TOOL MAGAZINE   number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT   store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 19000 kg ATTACHMENTS   chip conveyor: yes   coolant unit: yes   ban ...

Makine iyi çalışma durumundadır.

Resimde gösterilen teknik veriler. Elle gösterilen parçalar gelmiyor.

Key data: 800 mm

Teknik detaylar resimde yer almaktadır. Elle gösterilen parçalar gelmiyor.
