star torna kullanılmış satılık

7 axes Max. spindle passage: Ø 16 mm Max. headstock stroke: 205 mm MAIN SPINDLE Spindle speed: 10000 1/min Spindle drive power: 3.7 kW Minimum C-axis resolution : 0.001 [degrees] SUB-SPINDLE - Max. rod end Ø: 16 mm - Spindle speed : 9000 1/min - Minimum resolution C-axis : 0.001 [degrees] TOOLS 5x Turning tool holder on linear slide 4x drilling unit incl. drilling holders (front/rear) 3x driven tools for transverse machining on linear slides 4x tools incl. drill holders for reverse side machining Driven Tools Speed : 7500 1/min Conveyor Bar Feeder FMB minimag 18/3200

510 J type - equipped with Iemca MiniBoss 325/37 new in 1996 - tool eye - accessories - Fanuc 18-TB Control

Type 660 - Iemca Boss 332E/32L new in 2005 - machine that has ever worked in oil - Fanuc 18i-TB Control

Sliding head lathe Star SR 38 Type A :::SPECIFICATIONS::: CNC Model: Fanuc CNC version: 31i model B Main spindle power: 11Kw Main spindle bar clearance: 38mm Headstock stroke (Z1): 320mm Main spindle speed: 7000 Number of linear axes: 7 Number of fixed tool holder plate positions: 14 Number of driven tool holder plate tool slots: 7 Rapid feeds for linear axes X Y Z: 36m/min High refrigerant pressure: yes External tank system with filter: yes Sub-spindle: yes Sub-spindle speed: 7000 Power against spindle: 5.5Kw Bar clearance: 38mm Number of motorized rear tools: 8 Coolant Used: Neat Oil Model and brand of bar loader: Iemca Boss 552-HD for 4 meter bars Chip conveyor: belt conveyor :::D DIMENSIONS AND WEIGHT::: Length: 2740mm Width: 1315mm Height: 2120mm Weight: 4300Kg

Key data: 205 mm, 20 mm, 205 mm

Swiss lathe Star SR 20 Control Fanuc 16 T Spindle passage 20 mm Headstock travel 205 mm Spindle power 2.2KW/ 3.7KW Number of Powered Tools 3 Sub-spindle Conveyor belt Weight approx. 1,700 KG Bar magazine FMB Mini-Turbo

turning diameter over bed: mm spindle passage: 23 mm turning length: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specifications: first-class condition, only approx. 9000 operating hours Fanuc, High Performance CNC Control Series 31i-B5, 3-channel control, 3 turrets, 12 CNC axes, (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3), Rapid traverse speed 30 mm/min, Rod diameter max. 38 mm, Turning length max. 350 mm, Main spindle, speed max. 7,000 rpm, C-axis 0.001 degrees, Main spindle drive power 11 kW Sub-spindle speed max. 7,000 rpm, C-axis 0.001 degrees, Sub-spindle drive power 7.5 kW Turret speed max. 5,700 rpm, (with appropriate tool holder also higher) Turret drive power 4 kW Tool holder stations for a total of 30 (10 per turret) (prepared for internally cooled tools) Tool holder set, (non-driven) Guide bush unit (pull system, JBS) Oil cooler unit High-pressure conveyor (with integrated high-pressure unit) type Müller combistream CS 3 Coolant use: Oil Weight: 6.25 tons Dimensions: ( ...

Year of Build 2003 (0450) FANUC 16i-T control with 9 axes, 9 axes (X/C1/Y/E/B/A/X/c2), Rod Ø max. 13 mm Turning length max. 205 mm, Main spindle, speed max. 12,000 rpm, C-axis, Sub-spindle with collet, speed max. 12,000 rpm, C-axis, 4-fold tool holder 3 cross drilling rigs 8-station turret various additional tool holders, quills, Fire extinguishing system Kraft und Bauer Parts Conveyor Belt Manuals Operation/Programming/Electrics/Spare Parts Operating Tool Machine Up to 29 turning tools and up to 19 operated tools Tools possible 9.0KVA Fuel tank capacity 170L Charging magazine FMB Turbo 2-16 /3200/A / from Ø2- Ø20 mm / Coolant Insert of Machine: Oil Machine dimensions: approx. 2700 x 1400 x 1700 [mm] Machine weight: approx. 1700 [kg] Dimensions loading magazine: approx. 4300 x 600 x 1800 [mm] Weight loading magazine: approx. 700 [kg] Dimensions of the perip ...

gebr. CNC Swiss lathe STAR SR20R, built in 2001 Control, Fabr. Fanuc, 18i-T Series, 7 axes (X/Z/Y/C1/X1/Z1(C2), Rod Ø max. 20 mm, Turning length max. 205 mm, Main spindle, speed max. 10,000 rpm, C-axis 0.001 degrees, Sub-spindle with collet, speed max. 8,000 rpm, C-axis, Tool holder for a total of 19 tools (linear tool holder, front apparatus, reverse side machining), Parts Conveyor Belt, Standard Guide Bushing Unit Charging magazine FMB turbo 3-26/3200 / A /, year 2001 Coolant use of the machine: oil. Kraft & Bauer extinguishing system The machine can be viewed under power by appointment. Changes and errors in the technical data and specifications as well as Subject to prior sale! used CNC sliding headstock lathe STAR SR20R, year 2001 control, make Fanuc, series 18i-T, 7 axes (X/Z/Y/C1/X1/Z1(C2), bar-Ø max. 20 mm, turning length max. 205 mm, main sp ...

Inv. Num. : 8240 Type: KNC 32 Producer: STAR Created: 1990 Parameters: Control System: Fanuc Series O-TT Maximum turning length: 310 mm Max. turning diameter: 32 mm Maximum main spindle power: 8 kW Maximum spindle speed: 6000 1/min Length: 3100 mm Width: 1900 mm Height: 1900 mm Weight: 4000 kg

STAR ECAS 32T CNC lathe was built in 2005 in Japan by STAR MICRONICS CO., LTD. The machine, designed for the precise machining of complex workpieces, is used in many industries, such as automotive and aerospace. Its extensive machining capabilities facilitate complex machining processes, such as turning, drilling and threading, both on the front and back of the workpiece. Compared to other lathes available on the market, the offered STAR ECAS-32T swiss-type lathe stands out with the use of 11 axes, two 10-position turrets and two spindles (main spindle and sub-spindle). The extremely rigid design, in turn, provides the incredible process stability which is necessary to achieve excellent precision and quality of the produced parts. All this is complemented by intelligent CNC control, in which even the most advanced work programs are created in just a few steps. The STAR MICRONICS ECAS  ...

STAR ECAS 32T CNC lathe was built in 2007 in Japan by STAR MICRONICS CO.,LTD. The machine, which combines high performance and precision, has been designed to improve the machining of even the most complex workpieces. Its extensive machining capabilities facilitate complex machining processes such as turning, drilling and threading, both on the front and back of the workpiece. This makes the STAR MICRONICS ECAS 32T CNC lathe indispensable in many industries, such as the automotive and aerospace. The STAR ECAS-32T swiss-type lathe is equipped with, among others, 11 axes, two spindles (main spindle and sub-spindle) and capacious turrets that can accommodate many tools for any type of machining. The maximally rigid design additionally ensures incredible process stability, which is essential to achieve excellent precision and quality of the produced parts. The total weight of the machine  ...

Star SR 32 J III Type B Year of Make: 2022 Machine is not yet for sale, but you are welcome to send us your offer today.

Manufacturer: Star Model: ECAS-32T Year of Manufacture: 2005 Frequency: 50/60 Hz Power: 8.0 KVA The machine comes with an automatic bar feeder and oil mist filter. Automatic Bar Feeder: Manufacturer: FMB Model: TURBO 3-36/3200/A Year of Manufacture: 2006 Find more here - / Contact us at -

Manufacturer: Star Model: ECAS-32T Year of Manufacture: 2007 Voltage: AC 200V (3 Phase) Frequency: 50/60 Hz Power: 8.0 KVA Weight: 5700 Kg The machine comes with an automatic bar feeder and oil mist filter. Automatic Bar Feeder: Manufacturer: FMB Model: TURBO 3-26/3200/A Year of Manufacture: 2008 Find more here - / Contact us at -

Max. rod Ø 20 mm Max. headstock stroke 205 mm Spindle speed 500 - 10,000 1/min Max. rod Ø sub-spindle 20 mm Max. speed sub-spindle 8,000 1/min Number of tools that can be used: 22 Turning Tools Multiple Chisel Holders: 6 Driven tools for transverse machining: 3-8 Front side drilling tool: 4 Rear Reamer: 4 Speed driven tools: 8,000 1/min Bar Feeder FMB turbo 3-26

Control FANUC 18i-TB Max. rod Ø 32 mm Max. headstock stroke 310 mm Spindle speed 350 - 7,000 1/min Max. rod Ø sub-spindle 32 mm Max. speed sub-spindle 350 - 7,000 1/min Number of tools that can be used: 21 Turning Tools Multiple Chisel Holders: 6 Driven tools for transverse machining: 3 Front side drilling tool: 4 Rear Reamer: 4 Back side machining: 4 Speed driven tools: 5,000 1/min Bar feeder FMB turbo 3-36

STAR Swiss lathe S16-R, built in 2001 Swiss lathe SA16-R, Ø16mm with FMB Minimag magazine Pick-up spindle Parts Conveyor Belt Coolant system only ran on oil no chip conveyor

Max. rod Ø 20 mm Max. headstock stroke 205 mm Spindle speed 500 - 10,000 1/min Kdowjyb R Awsvu Nu Ieg Max. rod Ø sub-spindle 20 mm Max. speed sub-spindle 8,000 1/min Number of tools that can be used: 22 Turning Tools Multiple Chisel Holders: 6 Driven tools for transverse machining: 3-8 Front side drilling tool: 4 Rear Reamer: 4 Speed driven tools: 8,000 1/min Bar Feeder FMB turbo 3-26

This STAR SR-20 R II Lathe was manufactured in the year 2004. It is equipped with a Fanuc Series 18i-TB control unit and has 7 axis. The machine has a spindle speed of 500-10000 rpm.

This 7-axis Star SR-20J type C Swiss Type Turning was manufactured in 2015. It features a maximum machining diameter of 32mm, headstock stroke of 310mm, and spindle speeds up to 7,000rpm. Equipped with a Hydrajet BF20-2000 high-pressure coolant system and an Absolent A.Mist 10S mist extraction unit, the Star SR-20J type C represents a robust addition to any machining setup. Contact us for further details regarding this Swiss Type Turning.

Key data: 32 mm, 32 mm, 330 mm

CNC Longitudinal Lathe Brand: Star Machine type : SR 32 / 330 Year of manufacture : 1997 Control : - FANUC 16 TCNC Control Location : Hultsfred warehouse Sweden Availability : direct from stock Technical data Max. rod diameter: 32 \[mm\] Main spindle stroke: 310 \[mm\] Main spindle stroke with driven taper: 295 \[mm\] Spindle Power: 7.5 \[kw\] Main spindle speed : 350 – 7000 \[rpm\] C axis on main spindle Number of Turning Tool Holders: 6 Number of powered tool holders: 4 Driven Tools Speed: 350-5000 \[rpm\] Number of tool holders on the combi device: 4 maxi diameter in pick-up spindle: 32 \[mm\] Spindle speed counter spindle : 350-7000 \[rpm\] Power sub-spindle: 3.7 \[kw\] Indexing C-axis sub-spindle: 1° Pick-up spindle stroke: 125 \[mm\] Electrical connected load. : Power: 20 \[kW\] Dimensions: 1700 x 2515 x 1700 \[mm\] W ...

This 3-axis Star SR 20 R III was manufactured in 1996. It features a max turning diameter of 20 mm, spindle speeds up to 8,000 RPM, and a rapid feed rate of 35 m/min. Ideal for precision turning, it also includes six fixed turning tool stations and five radial driven tool stations. If you are looking to get high-quality turning capabilities, consider the Star SR 20 R III machine we have for sale. Contact us for more information.

This Star SR 20 J Type C was manufactured in 2011. It features a max turning diameter of 20 mm, spindle speeds up to 8,000 rpm, and a spindle power of 2.2 kW. The machine includes six fixed turning tool positions and five radial motorized tools. Ideal for precision Swiss-type turning, it has a compact footprint of 2.20 × 1.20 m. Contact us for more information about this machine.

This 5-axis Star SB-20R type N was manufactured in 2014, featuring a CNC Fanuc 0i-TD, C-axis on both main and sub-spindles, and a 6-position tool holder. It includes a 5-spindle unit for cross drilling, a sub-spindle with a 20mm part picking capacity, and a standalone coolant tank. Ideal for precision small parts production. If you are looking to get high-quality turning capabilities, consider the Star SB-20R type N machine we have for sale. Contact us for more information.

Key data: 20 mm, 205 mm

Star ECAS 20 CNC Swiss Automatic Lathe CNC control Star NICS (Yaskawa-Siemens 840DI) Turning diameter 20 mm Turning length 205 mm Spindle diameter 20 mm Spindle speed 500-10,000 rpm Spindle motor 3.7/2.2 kW Min. indexing C-axis main spindle 0.001° Min. indexing C-axis subspindle 0.001° Number of tools on the tower 16x Spindle torsion driven tools 8,000 rpm FMB Turbo 3-26 (3200) LxWxH 6850x1150x1765 mm If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.

This Star SB-16 was manufactured in 2005. It features a robust FANUC control system, separate coolant tank, automatic central lubrication, and a 6-station tool holder. Ideal for precision turning, it includes a 4-spindle drill holder and a comprehensive workpiece removal system. Consider the opportunity to buy this Star SB-16 swiss type turning machine. Contact us for more information.

This 3-axis Star SR-20J N was manufactured in 2019. Its a Swiss type turning machine designed for precision and efficiency. Ideal for intricate machining tasks, this model offers robust performance in a compact footprint. If you are looking to get high-quality turning capabilities, consider the Star SR-20J N machine we have for sale. Contact us for more information.

Swiss type turning machine manufactured in 2000. This Star SR 20 R was designed for precision turning with a maximum turning diameter of 20 mm and a spindle speed of 8,000 rpm. It features 6 fixed turning tool stations and 4 radial motorized tool stations, providing versatility for various applications. Consider the opportunity to buy this Star SR 20 R swiss type turning machine. Contact us for further details.

Linear guide carriage STAR 1651-514-10 rail width: 34 / 45 mm New ! Dimensions: 160 x 140 x 55 mm

STAR 1653-524-10 New !

STAR 1631-393-10

Linear guide carriage Star 1651-294-10

Open Linear Bearing Unit STAR 1067-630-40 067-30 Diameter: Ø 30 mm Foot: 84 x 60 mm New ! Dimensions: 84 x 68 x 59 mm

NC sliding headstock lathe Star SE 16 FMB Minimag bar loader high pressure coolant pump, Control: Fanuc 21i-TB

Edge milling machine, edge milling device, chamfering machine, mobile milling machine, weld edge former, weld edge former, weld preparation, weld edge forming machine, deburring device, deburring machine -Edge milling machine: with sliding carriage, maximum travel 500 mm -Depth adjustment: 0 - 6 mm -Drive: 0.5 kW -Adjustable speed: 1200 - 8000 rpm -Angle: 45° -Accessories: Widia milling head, diamond grinding wheel, vacuum cleaner -Dimensions: 490/870/H1150 mm -Weight: 106 kg

turning diameter over bed: n mm spindle passage: 20 mm turning length: mm Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bar material dia.:38 mm turning length:350 mm turning speeds:7.000 / 7.000 U/min number of tools:30 (3 x 10) driven tools:ja / yes control:FANUC 31i-B5 rapid traverse:30 m/min total power requirement:10,5 kVA weight of the machine ca.:6,5 t dimensions of the machine ca.:2,50 x 1,45 x 1,75 plus Lademagazin m work piece power:4 kW toolpiece turning speed range:5.700 1/min main spindle power:11 kW sub spindle power:7,5 kW CNC sliding headstock machine STAR ST 38, 3 turrets, 12 CNC Axis (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3, Fireextinguisher KRAFT und BAUER FB 703, partscatcher and conveyor belt (for long parts), LTA oilmist suction, chiller for oil, machining with oil as coolant, reading hours: approx. 14.500 hours "machine on", approx. 4.100 hours "machining"

bar material dia.:13 mm turning length:205 mm turning speeds:12.000 / 12.000 U/min number of tools:29 driven tools:ja / yes 19 control:FANUC 16 iT total power requirement:9 kVA weight of the machine ca.:1,7 t dimensions of the machine ca.:2,7 x 1,4 x 1,7 m CNC sliding headstock machine, subspindle,Year 2003 (0450) FANUC 16i-T control with 9 axes, 9 axes (X / C1 / Y / E / B / A / X / c2), Main spindle, speed max. 12,000 rpm, C-axis, Counter spindle with collet, speed max. 12,000 rpm, C-axis, 4-fold tool holder 3 transverse drilling apparatuses Revolver with 8 stations various additional tool holders, quills, Extinguishing system Kraft and Bauer High pressure system SF-Systeme Büchele /SHD 150/ 150bar / 2 x 40 um /3 valves, Parts conveyor belt Manuals Operation/Programming/Electrical/Spare Parts Operating tool machine Up to 29 turning tools and up to 19 attachments possible 9.0KVA Tank ca ...

Machine according to DIN 8605: lathe with increased accuracy. Top width: 700 mm Tip height: 170 mm Swing over bed: Ã? 340 mm Swing over cross slide: Ã? 190 mm Bed width: 260 mm Longitudinal slide displacement: 600 mm Cross slide displacement: 220 mm Upper carriage displacement: 110 mm Plan carriage length: 410 mm Plan slide width: 150 mm Bed slide length: 380 mm Turning tool cross section: 20 x 20 mm Distance turning Center - upper carriage: 34 mm Range of the upper carriage (support): 60 / 120 ° Main spindle: Spindle connection DIN 55029 (camlock): S 5 spindle bore: Ã? 50 mm Internal cone according to DIN 7178: 1:22 spindle diameter in front bearing: Ã? 70 mm Maximum Chuck diameter: Ã? 200 mm Faceplate diameter: Ã? 200 mm Spindle speeds: 40-3000 rpm Speed: Stepless mechanical speeds: 4 Main drive: Power at 40% ED: 5,3 kW Maximum nominal torq ...

Tip height: 330 mm centre distance: 1500 mm circular diameter: bed 690 mm spindle bore: 82 mm spindle retainer: short taper size 8 taper tailstock: 6 MK spindle speed: 7.1-1400 rpm feeds: longitudinal/plan 0.05 112/0.025 56 mm / U thread pitches: 0.25-560 mm electrical connection: 380 V, 15 kW space: 3350 x 1800 x 1400 mm weight: 4800 kg

Tip height: about quilt 300 mm centre distance: 1500 mm circular diameter: upper bed 640 mm spindle bore: 67 mm spindle retainer: Gr. 8 taper tailstock: 5 MK spindle speed: 18 - 900 rpm feeds: longitudinal/plan 0.063 0.032 2.1 mm / U thread pitches: 0.5-14 mm electrical connection: 380 V, approx. 7.5 kW space: 1550 x 3100 x 1250 mm weight: approx. 3500 kg hardly used and therefore well-preserved bed lathe

Control SIEMENS 805 TECHNICAL DATA: WORK AREA / DIMENSIONS Swing over bed [mm] 820 Swing over facing slide [mm] 515 Displacement of the plan slide [mm] 520 Displacement of the upper support [mm] 250 Turning length [mm] 2000 Tip height on flat railway [mm] 400 Bed width [mm] 560 Bed sleigh length [mm] 800 Facing slide width [mm] 320 Plan valve length [mm] 1005 Upper support width [mm] 200 Turning tool cross section according to DIN 770 hxb [mm] 40 x 25 MAIN SPINDLE Spindle nose according to DIN 55 027 [Gr.] 11 Spindle diameter in front bearing [mm] 170 Spindle bore [mm] 128 Inner taper of main spindle [metr.] 136 MAIN drive infinitely adjustable three-phase motor (AC motor) Power 60% / 100% ED [kW] 46/37 Torque max 60% / 100% ED [NM] 5,300/4.260 Torque max 60% / 100% ED [NM] 5,300/4.260 Total speed range [min-1] 6.3 1,600 Transmission levels 2 Speed rang ...

Made in Italy machine according to DIN 8606 Tip height: 260 mm Turning diameter over bed: 520 mm Swing over carriage: 300 mm Centre distance: 1500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (24) 9-1600 rpm (option 11-2000 U/min) Engine output: 5.5 kW (option: 7.5 kW) feed Z-axis: (93) 0.028 6.43 mm / Rev Feed x axis: (93) 0.012 2.73 mm / Rev Thread, metric: (54) 0.5-224 mm Thread, Witworth: (55) 72 - 1/8 TPI Thread, module: (54) 0.5-112 mm Thread, Diametral Pitch: (54) 64 - 1/4 D.P.. Cross slide Lxw: 650 x 230 mm Transversal carriage stroke: 340 mm Upper carriage Lxw: 350 x 150 mm Upper carriage stroke: 150 mm Tailstock Quill diameter: 85 mm Tailstock Quill stroke: 200 mm Tailstock taper: MK 5 Weight: 3,100 kg Facilities: -Movement of the tailstock pneumatically supported -Acceptance Protocol according to DIN 8605, ...

Made in Italy machine according to DIN 8605: lathe with increased accuracy. Tip height: 215 mm Turning diameter over bed: 430 mm Swing over carriage: 240 mm Top width: 1,000 mm Bed width: 290 mm Spindle bore: 52 mm Spindle nose: Camlock 6 " Spindle speeds variable: 6 Spindle speeds: 60-2,000 rpm S6/S1 engine power: 4 kW (option: 5.5 kW) feed Z-axis: (38) 0.05 - 1.88 mm / Rev Feed x axis: (38) 0.02 1,084 mm / Rev Thread cutting, metric: (30) 0.45-20 mm Thread cutting, Witworth: (35) 80-1 3/4 TPI Thread cutting, module: (25) 0.25-10 mm Thread cutting, Diametral Pitch: (30) 160-3 1/2 D.P.. Cross slide Lxw: 370 x 190 mm Transversal carriage stroke: 240 mm Upper carriage Lxw: 275 x 115 mm Upper carriage stroke: 120 mm Tailstock Quill diameter: 60 mm Tailstock Quill stroke: 135 mm Tailstock taper: MK 4 Weight: approx. 2,000 kg Facilities: -Infinitely variable  ...

Made in Italy Peak: 300 mm Rotary diameter over bed: 600 mm Rotary diameter via sled: 380 mm Peak: 1,500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (12) 16-1200 U/min Engine power: 9.2 kW (special equipment/standard: 7.5 kW) Reprimor Z-axis: (93) 0.028-6.43 mm/U Feed X-axis: (93) 0.012-2.73 mm/U Thread, metric: (54) 0.5-224 mm Threads, Witworth: (55) 72-1/4 x8 TPI Thread, module: (54) 0.5-112 mm Threads, Diametral Pitch: (54) 64 -1/4 D.P. Crossleigh hub: 340 mm Oberslitten hub: 150 mm Riding stock pinol diameter: 85 mm Riding stove pinol stroke: 200 mm Ridstock cone: MK 5 Weight: About 3,200 kg Facilities: -3-axis digital display -Step-by-step speed adjustment -Automatic lubrication of the management railways -LED lighting -Micrometer bed strike -9.2 kW engine instead of 7.5 kW -Quick change holder system mul ...

Tip width: 700 mm Tip height: 150 mm Circulation diameter over bed: 300 mm Bed width: 180 mm Spindle bore: 38 mm Mounting in the spindle bore: MK 5 Speed range, infinitely variable: 30 - 450 / 150 - 3000 rpm Range of longitudinal feeds: (14) 0.07 - 0.65 mm/U Area of plan feeds: (11) 0.03 - 0.12 mm/U Metric threads: (18) 0.2 - 3.5 mm Inch Thread: (21) 8 - 56 Gg/1" Pinole path: 85 mm Pinole holder: MK 3 Engine power S1 100%: 1.5 kW / 400 V Motor recording power S6 40%: 2.2 kW / 400 V Machine dimensions (W x D x H): 1380 x 640 x 500 mm Weight approx.: 235 kg without base Delivery: - Digital display - 3-jaw chuck PO3-160 mm steel version - Feed flange 160 mm - Solid grain tips - Interchangeable wheels - Quick-release steel holder size 20-2 with 2 straight inserts - Slip clutch - Micrometer longitudinal stop - Plan sled with top support - Frequency inverter ...

Center height 660 mm Center width 11000 mm Turning diameter 1320 mm Turning max. via support 950 mm Power 55 KW Torque 35000 Nm Clamping max. 1200 Workpiece weight 14 to Accessories: Bezel 200-630 mm

Tip height: 102 mm Top width: 450 mm Spindle bore: 32 mm Reduction gear Links.-right rotation 2-stage drive Vario speed: 270-3000 rpm Knee circuit Turning diameter over bed: 200 mm Spindle nose: W 20 Tailstock Quill: MK 2 Dimension (Lxwxh): approx. 140 x 56 x 123 cm Weight: approx. 550 kg Accessories available Manual available The machine is located in a clean good condition!

Lathe

Lathe

Lathe

Qty. 1 Second-hand roll lathe Mfc.: Herkules Type: WD-700 Built: 1952 General overhauled by Hoesch-MFD in 1990 Centre height: 600 mm Turning length: 2750 mm 2-axis digital display – Mfc.: Micro Wizard Longitudinal drive Standstill torque: 14 Nm Rated revolution: 2500 RPM Feeding range: 5 – 100 mm/min. Rapid speed: 2500 mm/min. Plain drive Standstill torque: 14 Nm Rated revolution: 3000 RPM Feeding range: 5 – 100 mm/min. Rapid speed: 2500 mm/min.

1 x L+Z lathe Colchester Mascot 1600/600 Built: c.1975 Very stable lathe. Ideal machine for locksmiths or agricultural machine mechanics. Technical data: Turning diameter over crimson: 710 mm Turning diameter over bed:432 mm Turning diameter via support:267 mm Turning length: 1,000 mm Spindle speeds:20 - 1600 rpm Spindle bore:76 mm Drive motor:5.6 kW Feeds: 0.6 - 10 mm/u Metric threads: 40 (0.4 - 14 mm incline) Machine weight approx.:2000 kg Room requirements approx.:l:2.65 x w:1.1 x h:1.6 m Accessories: 3 - Jaw lining UVA 310 mm 4 Set of change jaws Bfraed8ae0 Tripan quick-change system 4 x Interchangeable holder running counter tip in tailstock (MK 5) Countertip in spindle Alternating wheels Manual Mudguard complete documentation The machine can be inspected at our warehouse in Reichenbach under electricity.

Tip height: 130 mm Top width: 450 mm Rotational speed: approx. 55-3000 rpm Pneumatic clamping system Spindle nose: W 25 Div. W25 collets available Div. holder available BERGER LAHR axis motors Combitec EIP E-500 control Manual control available Coolant system available Machine lamp available Machine feet available Dimension (Lxwxh): approx. 1400 x 560 x 1230 mm Weight: approx. 550 kg The machine is located in a clean good condition!

Tip height 102 mm Top width 450 mm Leit.-/ spindle Collets W20 available Rotational speed: approx. 210 3000 rpm Reduction gear Links.-right rotation 2-stage drive L x W x H: CA. 1760 x 595 x 1230 mm Weight: approx. 650 kg

New lathe. Distance between centers: 800mm. Swing: 350mm. Swing over carriage: 200mm. Spindle hole: 46mm. Speeds: 18. (31,5-2500rpm). Power: 4hp. Dimensions: 2050x1000mm. Weight: 1100Kgs. Equipped with chuck and steady rest.

New lathe. Distance between centers: 2200mm. Swing: 500mm. Swing over carriage: 330mm. Swing in gap: 690mm. Spindle hole: 52mm. Speeds: 18. (25-2000rpm). Dimensions: 3700x1000mm. Weight: 1750Kgs. Equipped with chuck and steady rest.

New lathe. Distance between centers: 1000mm. Swing: 500mm. Swing over carriage: 305mm. Spindle hole: 80mm. Speeds: 18. (19-1500rpm). Weight: 1680Kgs. Equipped with chuck and steady rest.

Table diameter 1450mm Max working diameter 1600mm Max height under crosstravel 1000mm Nr. 02 RAM Visualization by DRO 4 axes Good working conditions Machine weight18 ton

Demoor 825-320 oil country lathe. Distance between centers: 3000mm. Swing: 970mm. Swing in carriage: 700mm. Bore: 320mm. New electrical box. Carriage with cone copier. Equipped with chuck.

machine has live spindle for drilling and grinding face plate diameter mm 800 max. workpiece diameter mm 1000 max. workpiece height mm 750 max. diameter of external working mm 1000 Z axe mm 630 face plate revolutions 1 5 – 500 rpm main motor output kW 30 (40) machine dimensions length mm 4900 height mm 3830 width mm 4485 machine weight kg 16000 machine had DRO Tesla NS 642

Table diameter 2,000 mm Max. Turning diameter 2,150 mm Turning height 1450 mm Table speed 3-140 rpm Max. weight of the workpiece 12000 kg Milling spindle: Maximum speed 2,000 rpm Milling spindle Motor power 22 kW Total weight of the machine approx. 34,000 kg Machine complete with: C-axis: 360,000° Milling spindle 22 KW Tool changer 16 positions Tool changer for milling tools ISO 50 16 positions Complete cladding Conveyor Complete cooling system with filtration

Center height 660 mm Distance between the centers length 12000 mm Turning diameter 1320 mm Turning max. via support 950 mm Clamping max. 1200 Power 55 KW Torque 35000 Nm Bezel I 200-630 mm Workpiece weight 21 to Accessories: Conveyor

Key data: 330 mm, 635 mm, 210 mm

brand new, toolmaker accuracy DIN 8605 Center height 167 mm Center width 635 mm Circulation diameter. over bed 330 mm Circulation diameter. over cross slides 210 mm Circulation diameter. in the offset 480 mm Main spindle bore 40 mm Speed range 40 - 2500 rpm Cone in tailstock MK 3 Drive power 2.2 kW Standard equipment: - 2-axis digital display ACU-RITE® DRO 203 - Precision spindle bearing thanks to NSK® tapered roller bearings - Quick-change steel holder MULTIFIX® size MA - Chip collection tray with opening flap at the front - Movable steel holder protection - Rear splash and chip protection wall - Feed protection - Spindle cover - Removable bridge - Coolant system - Work area lighting - Thread clock - Large matt chrome-plated scales - Foot brake with brake pedal over the entire length -Operating instructions - CE declaration of conformity

Parallel lathe Geminis GE650S to be rebuilt. Distance between points: 1000mm. Flip on bench: 680mm. Flip on cart: 410mm. Flip over neckline: 850mm. Main hole: 84mm. Motorized trolley and charriot. Speeds: 18 (13-1000rpm). Main engine: 15hp. Plate and trolley protections and CE RD1215/97 certificate. Quick-change plate and turret.

Key data: 600 mm, 2000 mm, 400 mm

brand new, good handling due to feed switch via joystick and rapid traverse, full-fledged manual transmission with large speed range Technical data: Swing over bed 600 mm over support 400 mm Center height 300 mm Bed width 400 mm Center width 2000 mm Spindle bore 80 mm Speed range (21) 20-2000 rpm quill cone MK 5 incl. accessories: - Rear chip splash protection wall - Electr. Locked face plate/chuck protection - Guide and pull spindle cover - Coolant system - Machine light - Rapid traverse longitudinal and transverse/joy-stick - Feed longitudinal and transverse/joy-stick - Interchangeable wheels - 4-fold steel holder -Operating instructions additionally included in the price: - Fixed bezel 20 - 200 mm - Fixed bezel 180 - 340 mm - Mitlauf. Bezel 20 - 200 mm - Main motor 11 kW instead of 7.5 kW - Cross support machined with T-slots - Reduction gear for t ...

Machine weight: 39,000 kg Faceplate diameter 2000 mm number of supports: 2 pcs. Dimensions : Height 6280 mm width 6600 mm length 4800 mm Extras: Right support with turret head, left and side - sliders. Digital indication of NS 114. Technical condition at the time of sale: Defective rotary amplifier main drive-replacement is required. Require replacement of cables and wires external piping:-machine control cabinets. Repair and adjustment of electrical parts. Not operated since 1994 The maximum dimensions of a workpiece Height 1300 mm Diameter of 2000 mm Weight 15 000 kg

Vertical lathe KOLOMNA 1540 T CONVENTIONAL MACHINE READY TO INSTALL Spindle diameter 4.000 mm Working diameter 4.140 mm Max working height 2.060 mm Ram travel 1.250 mm Weight over spindle 100 ton Motor power spindle 100 kW Boring/milling unit included Nr.02 RAM with visualization by DRO Excellent conditions, mechanical really like a new.

Stepless guide and pull spindle lathe TC 250 V Peak height: 250 mm Circulation diameter via slide: 350 mm Orbital diameter in the croation: 695 mm Tip width: 1500 mm Spindle nose: DIN 55029, Camlock, size 6 Bed width: 305 mm Cross slide path: 272 mm Upper slide path: 155 mm Spindle bore: 80 mm Speed range, infinitely variable: (3) 30 - 2200 rpm Whitworth Thread: (45) 2 - 72 TPI Metric Thread: (39) 0.2 - 14 mm Diametral Thread: (21) 8 - 44 D.P.I Module Thread: (18) 0.3 - 3.5 module Longitudinal feeds: 0.04 - 1.00 mm/U Flat feeds: 0.02 - 0.50 mm/U Engine power: 5.5 kW Dimensions LxWxH, approx.: 2900 x 1175 x 2040 mm Weight, approx.: 2,200 kg characteristics: - Toolmaker accuracy - Stepless speed control (3 pre-level steps) - Finely-balanced main spindle - Stable machine bed with hardened and ground guides - One-piece cast base - Adjustable precision cone roll ...

Bridgeport EZ Path S Used machine (very good) Control type Cnc Built 2001 Hours K.a. Price 12,500 € net plus VAT Dimensions 3100x1850x1500 Weight 2500 kg Location Haiger Description Universal CNC cycle deer of the brand Bridgeport suitable for tooling, fixture construction, training as well as mold making • Circulation diameter: 430mm • Control: Fanuc 20T Technical data • Circulation diameter 430mm • Peak width 1000mm • Control Siemens Fanuc 20 T • Reitstock MK 4 • Multifix tool station • Speed 1-4000rpm • Connection 380V - 7.5 KW

Merli Clovis 70 heavy lathe. Distance between centers: 8000mm. Swing: 1650mm. Swing in carriage: 1170mm. Bore: 206mm. Bed width: 1000mm. Speeds: 16.(3-300). Maximun weight without steady rest: 15.000Kgs. Maximun weight with 1 steady rest: 20.000Kgs. Equipped with chuck of 1400mm. Equipped with DRO. Equipped with 2 steady rest. Equipped with CE protections and CE certificate for second hand machines.

Key data: 4000 mm, 5000 mm

Specifications Control SIEMENS SINUMERIK 840 Dsl Main dimensions and travels Face plate diameter 4,000 mm Circumferential diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Crossbar Vertical adjustment of the crossbeam 3,200 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support - 2740 + 2740 mm Vertical displacement of the chisel slider 1,800 mm Cross-section of the chisel slider 250x210 mm Side Support (Right) Vertical adjustment support -25 + 2170 mm Horizontal displacement of the chisel slider 1,000 mm Cross-section of the chisel slider 250x210 mm Turning diameter max./min. 4,500/2,500 mm Main Drive: Main motor power 100 kW Face plate speed range 0.63 – 63 rpm. Maximum torque at the  ...

Machine details Stock number 1105-03330 Machine type guide and pull spindle lathe Make ERNAULT-SOMUA Type Cholet 550 Year of construction 1990 Control type conventional Storage location FRANCE Country of origin France Delivery time immediately Freight base EX WORK price Technical details Turning diameter over bed 550 mm Turning diameter via support 500 mm Turning length 1100 mm Tip height 250 mm Spindle bore 52 mm Inner cone 136 Spindle speeds 32-1800 rpm Feeds - bed slide / lengthwise 0.05-07 mm/w Feeds flat slide 0.033-0.45 mm/min Total power requirement 13 kW Weight of the machine ca. 2,3 t Space requirement approx. 2870 x 940 x 1400 m Information accessories: PARAT steel holder 4 STUCK 3 bake lining dia 250mm 2 AXIS DIGITAL

harden machine 1x1x2m temperature max 1200C PLC Wärmebehandlungs Kammeröfen Wärmebehandlungs gienanth Schachtöfen Haubenöfen Härten Anlassen bei niedriger und hoher Temperatur Glühen Normalglühen Austenitisieren Spannungsfreiglühen Vorwärmen vor dem Schmieden Rollenherdöfen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt t ...

Maximum diameter to turn on the bench 2,110 mm Maximum diameter to turn on trolley 1,600 mm Maximum distance between platforms 12,830 mm Spindle hole diameter 155 mm Cone on spindle no. 120 metric Cone on spindle (with reduction) no. 6 clamps Cone on the counterpoint (6-bit reduction) no. 120 metrics Maximum stroke of the counterpoint 400 mm DSeed from the tool support plane to the axis of the 80 mm centers Main engine power 100 HP Spindle speed from 0.9 to 90 rpm with continuous variation Longitudinal feed no. 36: 0.2 to 12.8 Transverse advances No. 36: 0.1 to 6.6 Metric fillets #26: 1 to 42 Whitwoth fillets #17: 0.5 to 11 Quick forwards Maximum permissible load on the tips 50-60 ton Refrigerant liquid system

Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 4000mm. Spindle nose: 51mm. Motor power: 12,5cv. Equipped with universal chuck of 250mm and steady rest. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.

Peak height 2,600 mm Point distance 10,000 mm Closed bench 2,000x6,000 mm To be completed with CNC

Cazeneuve HB500 rebuilt lathe. Distance between centers: 2000mm. Swing over bed: 500mm. Swing over carriage: 220mm. Motor power: 10cv. Spindle nose: 40,5mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Equipped with universal chuck of 250mm and steady rest. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.

Height tips 220 mm Useful length 1,000 mm 42 mm bar pass

Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 750mm. Motor power: 12,5cv. Spindle nose: 51mm. Equipped with universal chuck of 250mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: Steady rest. Optional: CE back guard

Equipped with no. 03 guides Overhauled with: guide grinding, CN conversion, new electrical and hydraulic system, hydraulic self-centering installation, shaving conveyor; CN Fagor 8055 Numerical Control – BT Maximum turnerable diameter 1800 mm 3-grife hydraulic self-centering with a diameter of 1450 mm with tightening force 30 Ton with 30 bar clamp L max turnerable 3000 mm Spindle engine power 110 Kw Maximum rotation speed 180 rpm Fast value axles 4000 mm/min M3/M4 Spindle Rotation Inversion Possibility 4 speed ranges Hydraulic counterpoint Maximum capacity of workpiece on counterpoint 12500 Kg It is currently possible to work details of up to 3000 mm length but the extension pallet is available to be able to work details up to 8 m in length. (un revised); Machine installed and working

Platò diameter: 1300 mm Used lathe in good condition, available unless sold.

Max length 8,000 mm Maximum turning diameter above wagon 1,250 mm Max vault over guides 1,650 mm Maximum turning diameter under spindle 2,000x700 mm Displayed – two axes
