TITAN (PAMA) AFP 160 CNC Ram-Type Floor Boring and Milling M/C
ikinci elDoğrulanmış satıcı
Fiyat iste
Doğrudan satıcıya
1 / 5
Teknik veriler
· ID 170397838İkinci el makineler
- Durum
- ikinci el
- Üretim yılı
- 2007
- Konum
- ab Fabrikstandort
Identifikation
ÜreticiTITAN (PAMA)
ModelAFP 160 CNC
Kalem numarası1034-13924
Technik
Adet1
Açıklama
spindle diameter:160 mm
x-travel:6500 mm
y-travel:3000 mm
W-axis (spindle longitudinal):1000 mm
dimension of the ram:400 x 420 mm
ram stroke:1000 mm
bore spindle turning speed range:1 - 2000 U/min
spindle taper ISO:50
feed speeds:2 - 6000 - 8000 mm/min
rapid speed:8/10 m/min
total power requirement:100 kW
weight of the machine ca.:76 t
dimensions of the machine ca.:12 x 4 x 7,5 ( 5,4 ü.F. ) m
with CNC Steuerung HEIDENHAIN iTNC 530
autom. toolchanger 40-pockets
autom. Pickup Station for universal milling head,
and facing head
rotary table 2500 x 2500 mm , max load 25 to.
1500 mm longitudinal movement
floor plate 4000 x 2000 mm
measuring probe, chip conveyor and coolant attachment
x-travel:6500 mm
y-travel:3000 mm
W-axis (spindle longitudinal):1000 mm
dimension of the ram:400 x 420 mm
ram stroke:1000 mm
bore spindle turning speed range:1 - 2000 U/min
spindle taper ISO:50
feed speeds:2 - 6000 - 8000 mm/min
rapid speed:8/10 m/min
total power requirement:100 kW
weight of the machine ca.:76 t
dimensions of the machine ca.:12 x 4 x 7,5 ( 5,4 ü.F. ) m
with CNC Steuerung HEIDENHAIN iTNC 530
autom. toolchanger 40-pockets
autom. Pickup Station for universal milling head,
and facing head
rotary table 2500 x 2500 mm , max load 25 to.
1500 mm longitudinal movement
floor plate 4000 x 2000 mm
measuring probe, chip conveyor and coolant attachment
